LED High Bay Warehouse Lighting Fixture Anti - Aging Electrostatic Spray - Paint Processed
LED High Bay Warehouse Lighting Fixture Anti - Aging Electrostatic Spray - Paint Processed
LED High Bay Warehouse Lighting Fixture Anti - Aging Electrostatic Spray - Paint Processed
LED High Bay Warehouse Lighting Fixture Anti - Aging Electrostatic Spray - Paint Processed
Specifications
Brand Name :
SUNLUXX
Model Number :
HBL-120Watt
Certification :
CE RoHs
Place of Origin :
China
MOQ :
1
Price :
US$129.80/PCS unit EXW prices
Payment Terms :
T/T, Western Union
Supply Ability :
5000 Pieces per Month
Delivery Time :
5-8 work days
Packaging Details :
38cm*38cm*27cm/1pcs
Beam angle :
60 ° , 90 ° , 120 °
Lumen :
18000
LED Brand :
Nichia 3030
Life Circle :
45℃ 50000Hours
Operation Temp :
-40℃ ~ +45℃
DC output voltage :
48V
Description

Surface Anti-aging Electrostatic Spray-paint Processing LED High Bay Lamp Warehouse Lighting


Features

1. Perfect for warehouse lighting, garage lighting, supermarket lighting, factory lighting and shop lighting
2. Meanwell HBG series driver and Lumileds 3030 LED make the LED high bay light fixtures durable without quality headache.
3. Up to 33’(10m) mounting height

LED High Bay Warehouse Lighting Fixture Anti - Aging Electrostatic Spray - Paint Processed

Produce Code

HBL-60Watt HBL-80W 100W HBL-120W150W HBL-200W240W

Power 60Watt 80W 100W120W 150W 200W 240W
Input Voltage 90-305VAC
Input Current

60W:0.27A@220VAC 80W: 0.36A@220VAC 100W:0.45A@220VAC
120W:0.55A@220VAC 150W:0.68A@220VAC 200W:0.91A@220VAC
240W:1.10A@220VAC

PF>0.90@220VAC
DC output voltage60W:54V 80W100W120W150W: 48V
DC output current60W:1.05A 80W: 1.5A 100W: 1.9A 120W: 2.3A 150W:2.9A 200W:3.9A 240W:4.65A
Dimming (Optinal)3 in 1 dimming (PWM, 0-10V, Resistor),Dali
CCT4000K,5000K,5700K,3000K

Ra >70
5000K

Typical Flux

60W:9000Lm±5%,80W:12000Lm±5%,100W:15000Lm±5%,
120W:18000Lm±5%,150W:22500Lm±5%,200W:30000Lm±5%
240W:36000Lm±5%

LED BrandNichia 3030 and Lumileds 3030
Beam Angle60°,90°,120°
Operation Temp-40℃ ~ +45℃
Storage Temp-40℃ ~ +85℃
Life Circle45℃ 50000Hours
IP ClassIP66
IK ClassIK08
CertificateCE,ROHS
Body ColorBlack (default with RAL9005),Gray ( optional for RAL9007)


120Watt LED UFO Retrofit Kits High Bay Light Distribution
