Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Specifications
Brand Name :
PULLNER
Model Number :
PHFM
Certification :
FDA
Place of Origin :
Shanghai China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram, Paypal
Supply Ability :
800pcs per week
Delivery Time :
3-7days
Packaging Details :
Carton box after poly bag. 4pcs per carton
PHFM :
High Flow Filter
OD :
160mm
Length :
20"(508mm), 40"(1016mm), 60"(1524mm)
Material :
PP, PET, Glass Fiber
Filtration rating :
1um, 2um, 5um, 10um, 15um, 20um, 30um, 50um, 70um, 100um
Filtration area :
6.6㎡
Efficiency :
99.8%
Maximum Operating Temperature :
82℃
Maximum Operating Differential Pressure :
3.5bar@21℃
Flow rate :
60m³/h
Description

RO Pre-Filter 6.6㎡ area 5 micron Absolute Boiler Condensate Water
High Flow Filter with 160mm Diameter

General information
PHFM series high flow filter cartridge adopts 160mm large diameter structure with single open end. Use advanced pleat technology, provide bigger filtration area, high flow rate and long service life. All connection use thermal welding, no any adhesive, wide Chemical compatibility.

Material Construction

Filter Media

PP: Deep Pleated PP/Melt PP

FO: Organic Fiber

GF: Resin Synthetic Glass Fiber

Support/Drainage

PP

Organic Fiber

Polyester

End Cap Material

Fiberglass Reinforced Polypropylene

Fiberglass Reinforced Polypropylene

Fiberglass Reinforced Polypropylene

Performance

Maximum Operation Temperature

PP: 82℃

FO: 120℃

GF: 121℃

Maximum Operation Differential Pressure

PP: 3.44bar / 21°C

FO: 3.44bar / 120°C

GF: 3.44bar / 121°C


Flow Rate and Filtration Area

Size

(Diameter*Length)

Design Flow

(m3/hr)

Maximum Flow

(m3/hr)

Filtration Area

(㎡)

6"*20"

15

40

2.6

6"*40"

30

80

5.2

6"*60"

45

120

7.8



Performance comparison
Comparison chart of specific filter element number and corresponding filter footprint
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
Boiler Condensate Water Ro Pre Filter Cartridge 6.6m2 160mm
