40w Street Light Led Module For Road Lighting With 150*70 Degree 5 Years Warranty
40w Street Light Led Module For Road Lighting With 150*70 Degree 5 Years Warranty
40w Street Light Led Module For Road Lighting With 150*70 Degree 5 Years Warranty
40w Street Light Led Module For Road Lighting With 150*70 Degree 5 Years Warranty
Specifications
Brand Name :
LEPOWER(Shenzhen)
Model Number :
LY-MSL3063
Certification :
CE RHOS UL TUV CB SAA
Place of Origin :
Shenzhen
MOQ :
100pcs
Payment Terms :
T/T, Western Union,paypal
Supply Ability :
20000pcs per month
Delivery Time :
5-7 days
Power :
40W
Voltage :
DC 32-38V
CCT :
6000K
CRI :
Ra>70
IP rating :
IP66
Warranty :
5 years warranty
Packaging Details :
Neutral carton packing
Description

40w Street Light Led Module For Road Lighting With 150*70 Degree 5 Years Warranty

Product Feature

  1. Super-high luminous efficiency as 145lm/W, extra energy saving product;

  2. Eco-friendly:no lead,mercury and other substances to make bad effect on the environment.And no UV, IR and other harmful substances to human health.Compared with common metal halide lamp,it has no glare and without light pollution to surroundings.

  3. Perfect Light Distribution Solution:Adoption of integrated peanut shell optic lens, meet the photometric requirements of road lighting design standards,enhance the brightness , illumination uniformity and geometric utilization.

  4. When installed in the street,there are vents between modules to facilitate thermal

    dissipation by air convection and automatic cleaning of light.

  5. Operating temperature range: from 35 Celsius degree to 70 Celsius degree.

Parameter

40w Street Light Led Module For Road Lighting With 150*70 Degree 5 Years Warranty
Electrical
Specifications		 Model Power Input Voltage CCT CRI Luminous
Efficiency		 Flux

LY-MSL3063

 40W

DC

32-38V

 3000K
4000K
5000K
6000K		 ≥70 145lm/w 5800lm
Mechanical Specifications Beam Angle IP Rating

Lifetime

(hours)

 Warranty Material

Storage Temperature

 Operating
Temperature
150*70 IP66 >50,000 5 years

Aluminum+

Optical PC

-40℃~85℃

 -40~50 ℃

Packing information

Size

300*70*48.5mm
N.W. 0.52kg
Carton (40pcs) 510*330*330mm
G.W. (40pcs) 25kg

Size

40w Street Light Led Module For Road Lighting With 150*70 Degree 5 Years Warranty

Application

This module is 300*70*48.5mm standard size module, it can be matched to many different style led street light housing.

40w Street Light Led Module For Road Lighting With 150*70 Degree 5 Years Warranty

Warranty terms

  • 5 years warranty.
  • Under the terms of this warranty, if the product have a failure occurs under normal usage within warranty period, Lepower will provide free/rework new products based on the proof-documents
  • If Failure or damage due to incorrect operation, wire connection, or anything other do not follow our instruction, We will provide paid maintenance within warranty period.
