Specifications
Brand Name :
HAIYANG
Model Number :
HM05008
Certification :
ISO9001
Place of Origin :
China
MOQ :
10 Meter/Meters
Price :
0.5$/m(1~10m);0.43$/m(>1000m)
Supply Ability :
5000 Metric Ton/Metric Tons per Year
Packaging Details :
6m or 12m per piece
Specification :
DN20mm-630mm
Color :
Grey，white，black or request
Usage :
water supply
Raw material :
PE
Size :
Customized Size
MOQ :
100 Meters
Sample :
Provide Sample
Advantage :
High Quality
Length :
as costomer requirements
Description

PE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mm

----------------------------------------

Basic Info.

The main features of HDPE pipes are: good toughness and flexibility; small friction coefficient and strong passing ability; convenient construction, good chemical stability, long service life, suitable deflection, good resistance to rapid crack transmission, resistance to Low temperature, conform to the requirements of the times, "green" environmental protection.

Size PN2.0MPa PN1.6MPa PN1.25MPa PN1.0MPa PN0.8MPa PN0.6MPa
SDR 9 SDR 11 SDR 13.6 SDR 17 SDR 21 SDR 26
OD(inch) OD(mm) thickness thickness thickness thickness thickness thickness
1/2 20 2.3 2.3
3/4 25 3 2.3 2.3
1 32 3.6 3 2.4
1 1/4 40 4.5 3.7 3 2.4
1 1/2 50 5.6 4.6 3.7 3
2 63 7.1 5.8 4.7 3.8
2.5 75 8.4 6.8 5.6 4.5
3 90 10.1 8.2 6.7 5.4 4.3
4 110 12.3 10 8.1 6.6 5.3 4.2
5 125 14 11.4 9.2 7.4 6 4.8
5 140 15.7 12.7 10.3 8.3 6.7 5.4
6 160 17.9 14.6 11.8 9.5 7.7 6.2
7 180 20.1 16.4 13.3 10.7 8.6 6.9
8 200 22.4 18.2 14.7 11.9 9.6 7.7
8 225 25.2 20.5 16.6 13.4 10.8 8.6
10 250 27.9 22.7 18.4 14.8 11.9 9.6
11 280 31.3 25.4 20.6 16.6 13.4 10.7
12 315 35.2 28.6 23.2 18.7 15 12.1
14 355 39.7 32.2 26.1 21.1 16.9 13.6
16 400 44.7 36.3 29.4 23.7 19.1 15.3
18 450 50.3 40.9 33.1 26.7 21.5 17.2
20 500 55.8 45.4 36.8 29.7 23.9 19.1
22 560 62.5 50.8 41.2 33.2 26.7 21.4
24 630 70.3 57.2 46.3 37.4 30 24.1
28 710 79.3 64.5 52.2 42.1 33.9 27.2
32 800 89.3 72.6 58.8 47.4 38.1 30.6
36 900 81.8 66.2 53.3 42.9 34.4
40 1000 90.2 72.5 59.3 47.7 38.2
48 1200 88.2 67.9 57.2 45.9
55 1400 102.9 82.4 66.7 53.5
60 1500 110.2 88.2 71.4 57.6
65 1600 117.6 94.1 76.2 61.2

Advantage

Good fluid characteristics: The inner wall of the PE drainage pipe is smooth and not easy to scale, ensuring the smoothness of the drainage system and reducing pipeline resistance.
Environmentally friendly and recyclable: PE is a recyclable material that meets environmental protection requirements and is conducive to sustainable development and resource recycling.

Impact resistance: The PE material itself has excellent impact resistance, allowing the drain pipe to remain stable when impacted by external forces, reducing the risk of breakage.

Details

PE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mmPE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mmPE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mmPE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mm

Application

Construction projects: In construction projects, PE drainage pipes are used in building drainage systems, including drainage facilities such as stairs and bathrooms.
Farmland drainage: In the agricultural field, PE drainage pipes are used in farmland drainage systems to improve soil drainage and increase farmland productivity.
Industrial wastewater treatment: For wastewater treatment systems in industrial enterprises, PE drainage pipes can handle all types of wastewater and ensure safe discharge and treatment.

Certificate

PE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mm

PE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mm

PE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mm

Company Profile

Located in Jiangsu, with convenient water and land transportation. It is a comprehensive enterprise integrating research, development, design, application, production and sales. The company has production lines for PE water supply pipes with larger diameters, prestressed corrugated pipes, corrugated pipe production lines, PVC pipe production lines and other equipment. Specializing in the production of PE water supply pipes, prestressed corrugated pipes, HDPE corrugated pipes, plastic blind trenches, permeable pipes, etc. The products are mainly used in municipal administration, highways, railways, water conservancy, power, environmental greening and infrastructure construction, and are used in municipalities and expressways. Many national key projects such as railways and railways have been well received by engineering experts and users.


PE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mm PE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mm

PE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mm PE Water Supply Pipe Plastic Drainage Pipe Customized White Pipes 20mm 32mm

FAQ

Q: Where is your company?
A: We are located in Jiangsu, China.

Q: What is your warranty policy?
A: The product is guaranteed for two years from the date of shipment (or leaving the seller's factory depending on the terms).
It is also guaranteed that the product can be used for 50 years.
