GB150-2011 Oil And Gas Equipment , Well Test Separator Abrasion Resistant
GB150-2011 Oil And Gas Equipment , Well Test Separator Abrasion Resistant
GB150-2011 Oil And Gas Equipment , Well Test Separator Abrasion Resistant
GB150-2011 Oil And Gas Equipment , Well Test Separator Abrasion Resistant
Specifications
Brand Name :
CCSC
Model Number :
test separator
Certification :
ISO9001:2008,ASME,API
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
40-50days
Packaging Details :
Plywood box
Voltage :
220V/380V
Color :
Customization
Code :
GB150-2011
Corrosion allowance :
3MM
Description

3 Phase Separator /well test separator /separation machine for Surface Well Testing Equipment

3 Phase Separator - Test Separator is a horizontal steel pressure vessel designed to efficiently separate well effluent into three phases - water, oil, gas, for production well testing and frac flowback operation.

3 phast separator typically consists of a vessel, an oil flow-measuring system with dual meters, a flow-measuring system that utilizes turbine meters, and eletronic gas flow measurement systems with several sampling points, and two relief valves to protect the vessel against overpressure. To provide accurate measurements, the 3 phase separator is fitted with pneumatic regulators that maintain a constant pressure and a constant liquid level inside the vessel by control valves on the oil and gas outlets.

GB150-2011 Oil And Gas Equipment , Well Test Separator Abrasion Resistant

3 phase separator - test separator is fitted with a deflector plate, coalescing plates, a foam breaker, a vortex breaker, a weir plate, and a mist extractor. These components reduce the risk of carryover (liquid in gas line) and carry under (gas in liquid line) that would affect the flow rate measurement accuracy.

GB150-2011 Oil And Gas Equipment , Well Test Separator Abrasion Resistant

The typical sizes of 3 phase separator are 42" x 10' 1440psi, 48" x 12' 1440psi, the most popular brands for the key components are: Barton Recorder, Fisher Level Controller, Daniels Gas Orifice Meter, Balon Ball Valves, etc. we accpet all brands over the worlds based on clients requirement.
