Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Specifications
Brand Name :
Dingzun Cable
Model Number :
DZ216
Certification :
CE CCC
Place of Origin :
Shanghai, China
MOQ :
200M
Price :
1M/0.5~5USD
Payment Terms :
L/C, T/T
Supply Ability :
10000M/1DAYS
Delivery Time :
15DAYS
Packaging Details :
Carton Packing / Drum Packing
Conductor :
Bare Copper 32/0.20 IEC60228-5
Fire Barrier :
MGT
Insulation :
XLPE
Wire Diameter :
3.10
Cores/Pairs :
10cores stranded
Overall Shield :
Aluminum foil and tinned copper drain wire 7/0.30
Wrapping :
MGT
Inner Jacket :
LSZH blk thick. 0.90mm
Armor :
SWA galvanized steel wire
Outer Jacket :
LSZH gry thick. 1.40mm
Rated Voltage :
300/500V
Test Voltage :
1.5kv / 5min
Conductor Resistance :
18.30Ω/km at 20℃
Feature :
Low smoke halogen free
Description

Multi-Core Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10x1 – Robust and Reliable Signal Transmission for Industrial Applications

Designed for precision signal transmission in demanding environments, our 10-core Instrumentation Cable delivers exceptional performance and durability. Rated for 300/500V, this instrumentation cable features copper conductors (CU) with cross-linked polyethylene (XLPE) insulation, ensuring superior electrical properties and thermal stability.
Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
Key Features & Benefits:
- Enhanced EMI/RFI Protection: Multicore grounding tape (MGT) and overall screening (OS) minimize electromagnetic interference for accurate signal integrity.
- Flame-Resistant & Low Smoke Zero Halogen (FR/LSZH): Dual-layer sheathing reduces fire propagation and toxic emissions, enhancing safety in critical environments.
- Superior Mechanical Protection: Galvanized steel wire armor (GSWA) provides excellent crush resistance and protection against rodents and harsh conditions.
- Durable Construction: XLPE insulation resists moisture, chemicals, and temperature fluctuations for long-term reliability.

Applications:
- Oil & gas refineries
- Chemical processing plants
- Power generation facilities
- Industrial automation and control systems

Engineered for resilience and performance, our 10-core Instrumentation Cable ensures secure and interference-free operation in the most challenging industrial environments.

Instrumentation Cable 300/500V CU/MGT/XLPE/OS/FR/LSZH/GSWA/LSZH 10х1
