Specifications
Brand Name :
GDZX
Model Number :
GM-5KV
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 SET
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Packaging Details :
ROBUST CARTON
Output U :
50V, 100V, 250V, 500V, 1.0kV, 2.5kV, 5.0kV
Measuring range :
0～10TΩ
max error :
10%
Power :
14.8V Li-Battery
Short circuit current :
About 5mA
Temperature error :
±0.5℃
Description

Voltage Adjustable 5kV R15 R60 R600 DAR PI Insulation Resistance Meter

GM-5kv Adjustable High Voltage Digital Megger

Model GM-5KV
Rating test voltage 0V, 100V, 250V, 500V, 1.0kV, 2.5kV, 5.0kV
Output voltage error ± 5 %
Short circuit current 5mA

Product Overview

GM-5kV high voltage insulation resistance tester high voltage, the power, they often object to
be measured with a leak or high-frequency interference on inductive power, so for personal safety,
the use of this instrument must first take a good safety ground wire!


This instrument is designed for measuring Insulation characteristics of large high voltage transformers, electrical machinery electric appliance, remote power cables or buried cables, etc, solving the problem of filed interference in power plants, substations.

Performance Features

  • Microcomputer control, menu operation, LCD display, stable performance
  • Suitable for measuring in strong electromagnetic interference environment.
  • Wider measuring range, several voltage output gears.
  • Output voltage is continuous and adjustable
  • Auto measure R15, R60, R600, auto calculate DAR, PI
  • Strong load capacity, short-circuit current about 5mA.
  • Measuring range up to 0 ~ 10TΩ, auto switching range.
  • The analog bar pointer & digital display, clear and accurate
  • Test time display at any time, buzzer beeps every 15 seconds
  • Auto discharge high voltage within 30 seconds after test
  • Auto measure ambient temperature, air humidity, date and time.
  • Storage capacity up to 60 records, data may not be lost for 20 years.
  • RS232 serial interface
  • Built-in Micro-printer
  • Auto remind power off when no operation for 5 minutes
  • Perfect protection, high reliability

Key Specifications

  • Rating test voltage 50V, 100V, 250V, 500V, 1.0kV, 2.5kV, 5.0kV
  • Measuring range high limit 10TΩ
  • Output voltage error ± 5 %
  • Short circuit current About 5mA
  • First half range basic error ±( 5%·Rx + 1d )
  • Second half range basic error ±( 10%·Rx + 2d )
  • High voltage display error ±( 5%·Ux + 1d )
  • Temperature measurement error ±0.5℃
  • Air humidity measurement error ±2%RH
  • Power supply 14.8V lithium battery
  • Battery run time 30 days, every day 10 times DAR test & 5 times PI test
  • Insulation resistance >500MΩ(between test line and case)
  • Withstanding AC10.0kV 50Hz 1min(Test line to the case)
  • Temperature and humidity 0℃~+40℃ < 85%RH
  • Storage temperature and humidity -20℃~+50℃ < 90%RH
  • Dimensions and N.W. 320×230×270mm, 4.5kg
Product Details
Microcomputer Control 5KV Voltage Adjustable Insulation Resistance Test Equipment
Microcomputer Control 5KV Voltage Adjustable Insulation Resistance Test Equipment
Microcomputer Control 5KV Voltage Adjustable Insulation Resistance Test Equipment
Microcomputer Control 5KV Voltage Adjustable Insulation Resistance Test Equipment
Microcomputer Control 5KV Voltage Adjustable Insulation Resistance Test Equipment
Microcomputer Control 5KV Voltage Adjustable Insulation Resistance Test Equipment
Panel Introduction
Microcomputer Control 5KV Voltage Adjustable Insulation Resistance Test Equipment
1.L terminal socket
9.UP button
2.Display
10.DOWN keys
3.G terminal socket
11.OK keys
4.E terminal socket
12.Contrast knob
5.High pressure adjustment knob
13.RST Reset button
6.ESC key
14.switch
7.Temperature and humidity sensor
15.Charging jack
8.buzzer
16.RS232 serial interface

Instructions

Safety rules
Test begins, it should take a good test line, after turning the power meter.
The test is complete, you should turn off power to the instrument, after dismantling the test line.
When the meter is working, the body can not touch or near the test line.
Test the whole process, there must be full-time staff on-site supervision for safe operation.
