Specifications
Brand Name :
GDZX
Model Number :
ZXYZ-2000
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1
Price :
USD$2,500.00 - $3,000.00 / Sets
Payment Terms :
L/C, T/T, Western Union, MoneyGram,
Supply Ability :
1200 Cases per Year
Delivery Time :
8-15 Work days
Packaging Details :
Packed in wooden case or carton
Product Name :
Transformer loading tap switch tester
Output current :
1.0A, 0.5A, 0.3A gears
Working power :
AC220V ± 10%, 50Hz ± 10%
TTR measurement range: :
0.8~10000.
Volume :
320mm*240mm*130mm.
Weight :
3Kg
Brand :
GDZX
Description

Micro Computer System Power Transformer On Load Tap Changer Tester

Product introduction

This tester is mainly used to measure the transformer on-load tap-changer transition waveform, transition time, the instantaneous transition resistance, three-phase synchronization and so on.

The instrument features highly intelligent, English menu prompts, simple operation. Instrument small size, light weight, strong anti-interference ability. It is ideal instrument to ensure safe production and good quality in powerplants units, transformer manufacturing industry.

Features :


1. Large output current, light weight.
2. Open circuit voltage 28V, 1A gear for testing 10Ω transition resistance, 0.5A, 0.3A for larger transition resistance.
3. Perfect protection circuit, reliable to use.
4. Vertical chassis structure, 5.7-inch large LCD display, easy site operation.
5. U disk storage function


Product Parameters:

Output current

1. 1.0A, 0.5A, 0.3A gears

Resistance range

1.0A: 0.1 ~ 10Ω; 0.5A: 5 ~ 20Ω; 0.3A: 10 ~ 40Ω

Resistance measurement accuracy

± (reading × 5% + 5 words), resolution: 0.01Ω.
Transition time measurement range:

1 ~ 250mS.
Transition time measurement accuracy

± 1mS, resolution: 0.1mS.
Sampling frequency 10K
Storage

U disk storage, local storage.



Operating temperature

 -20 ℃ ~ +50 ℃
Environmental humidity ≤ 90% RH, no condensation
Working power

AC220V ± 10%, 50Hz ± 10%
