ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
Specifications
Brand Name :
GDZX
Model Number :
ZX2677E
Certification :
ISO9001
Place of Origin :
China
MOQ :
1Set
Price :
US $919.00-1879.00/SET
Payment Terms :
L/C,T/T,Western Union,MoneyGram,D/A,D/P,WeChat,Paypal
Supply Ability :
1200sets/year
Delivery Time :
7-20 work days
Packaging Details :
Packing wooden case or carton
Product name :
Digital high-voltage Insulation tester
Base conditions :
23°C±5°C，below 75%rh
Rated voltage(V) :
250;500;1000;2500;5000V;10KV;
Test Voltage(V) :
rated voltage*（1±10%）
Insulation Resistance Range(GΩ) :
0.01MΩ～2000GΩ
Voltage Range :
DC:0~1000V; AC: 0~750V
Power Supply :
12V rechargeable battery;
Data Storage :
500 groups, "FULL" symbol indicates that storage is full;
Instrument weight :
2750g(including battery);
Working Temperature and Humidity :
-10℃~+50℃,<85%RH;
Description
Portable 10KV 2000GΩ LCD Display Digital High-voltage Insulation Resistance Tester
Insulation Resistance Tester
Product introduction

ZX2677E Digital insulation resistance meter also known as megohmmeter, high voltage insulation resistance tester, etc., for the insulation resistance test. The instrument has a large LCD screen gray backlit display, data storage, data access, alarm, automatic shutdown and other functions. At the same time, it also has the function of measuring AC voltage absorption ratio and polarization index of DC voltage. The machine is beautiful and upscale, has a wide range, high resolution, convenient operation, easy to carry, accurate, reliable, stable performance, strong anti-interference ability. Moreover, it has a shockproof, dustproof, moisture-proof structure and is a commonly used and indispensable instrument for telecommunications, electricity, meteorology, computer rooms, oil fields, electromechanical installation and maintenance, and industrial enterprises that use electricity as industrial power or energy.

ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD DisplayZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display

Features

1. The instrument has a large LCD screen gray backlit display, data storage, data access, alarm, automatic shutdown and other functions.

2. The function of measuring AC voltage absorption ratio and polarization index of DC voltage.

3. Digital insulation resistance meter consists of medium and large scale integrated circuits.

4. The output power of the watch is large, and the output voltage level is a lot (with 6 voltage levels).

5. Rated insulation test voltage range 250V ~ 10kV, insulation resistance measurement range 0.01MΩ ~ 2000GΩ.

6. DC voltage measurement range 0 ~ 1000V, AC voltage measurement range 0 ~ 750V.

ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display


Technical Indicators

Function Insulation resistance test, voltage test
Base conditions 23°C±5°C,below 75%rh
Rated voltage(V) 250；500；1000；2500；5000V；10KV
Test Voltage(V) rated voltage×(1±10%)
Insulation Resistance Range(GΩ) 0.01MΩ～2000GΩ Resolution:0.01MΩ
DC Voltage Range 0～1000V Resolution:0.1V
AC Voltage Range 0～750V Resolution:0.1V
Output short-circuit Current ≥5mA(10KV)

Absorption Ratio and Polarization

Index Measurement

 Have
Power Supply 12V rechargeable battery
Backlight Controllable gray screen backlight, suitable for use in dim places
Dispaly mode 4-bit large LCD display, gray screen backlight
LCD display size 108mm×65mm
Instrument size L/W/H:277.2mm×227.5mm×153mm
USB interface With USB interface, software monitoring, storage data can be uploaded to the computer, save the print
Communication Line USB communication line 1PC
Test Line High voltage rob red 3meter, high voltage test line black 1.5meter, green 1.5meter
Data Storage 500 groups, "FULL" symbol indicates that storage is full
Data Review Data review function: "MR" symbol display
Overflow Display Exceed measurement range overflow function: “OL ” symbol display
Alarm Function Alarm when the measured value smaller than the alarm setting value
Power Consumption Standby: 30mA Max(backlight off), turn on backlight: 42mA Max, measure:300mA Max(backlight off)
Instrument weight 2750g(including battery)
Battery voltage When the battery voltage is low, low battery symbol “ battery ”will display
Automatic shut-down automatic shutdown after 15 minutes boot
Insulation Resistance ≥50MΩ(between Measuring line and housing)
Pressure Resistance AC3kV/50Hz 1min
Working Temperature and Humidity －10℃～+50℃＜85%RH
Storage Temperature and Humidity －15℃～+55℃＜90%RH
Suitable for Safety Regulations IEC61010-1,IEC1010-2-31,IEC61557-1,5,IEC60529(IP54) pollution grade 2,CAT Ⅲ 300V

ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display

Test cases
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display

ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD DisplayZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD DisplayZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD DisplayZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display

Company introduction
Wuhan GDZX Power Equipment Co.,Ltd. is a manufacturer of power test equipment, integrating design, production and sales, providing complete solutions for high-voltage testing and electrical testing services for various power users.The main products include:AC series resonance test device, high voltage test equipment, transformer test equipment, secondary protection / switch test equipment, cable fault tester, arrester test equipment, power metering equipment, standard source series and so on. There are many kinds of products and complete models.
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD DisplayZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD DisplayZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display

ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
ZX2677E Portable 10KV Digital Insulation Resistance Tester Shockproof With LCD Display
