Specifications
Brand Name :
GDZX
Model Number :
ZXTX Series
Certification :
ISO9001
Place of Origin :
China
MOQ :
1Set
Price :
US $1989.00-$4236.00 /SET
Payment Terms :
L/C, T/T, Western Union, MoneyGram, D/A, D/P, WeChat, Paypal
Supply Ability :
1200sets/year
Delivery Time :
7-20 work days
Packaging Details :
Packing wooden case or carton
Product name :
Multifunction Process Calibrator
DC V :
0-60.000V (Upper Display+/-30V)
DC mA :
0-24.000mA(Upper Display+/-24mV)
DC mV :
-15.000mV-125.00mV
Frequency :
1.000Hz-99.999kHz
Resistance (4wires) :
0.00Ohm-3200.00Ohm
Description

DC 24V Handheld Multifunction Process Calibrator For Site


Product introduction

The ZXTX series multifunctional process Calibration instrument is a high precision hand-held signal measurement / output instrument, which can measure and output voltage, current, resistance, frequency, thermocouple at the same time. Various industrial process signals, such as thermal resistance, can be used to calibrate pressure transducers with external high precision intelligent pressure modules. It can replace current signal source, voltage signal source, resistance box, electronic potentiometer, frequency meter and other measuring and calibration instruments. Mainly used in industrial field signal calibration, fault diagnosis; also applicable to chemical, military and all kinds of research institutes, real Signal measurement and calibration in laboratory.

DC24V Handheld Multifunction Process Calibrator For SiteDC24V Handheld Multifunction Process Calibrator For Site

DC24V Handheld Multifunction Process Calibrator For Site

Features

1.Super strong protection function: waterproof grade IP67, arbitrary signal end misconnect 220 V automatic protection.
2.Measurement / output: voltage, current, frequency, resistance, in which current output supports active, passive.
3.The thermal resistance and thermocouple are simulated in the form of temperature.
4.Can simulate two-wire transmitter.
5.The accuracy was 0.02% ;0.05%.
6.Two isolated channels support synchronous measurement and output.
7.Can provide manual step, automatic step, 0-100% step and slope output function;
8.With white LED backlight, manual backlight adjustment and automatic power off function, suitable for field use.
9.Provide DC24V circuit power suppcalibration;ly for field debugging.
10.Unique automatic identification of three-wire, four-wire connection mode.
11.Support customer self,Band on-off test function.
12.Thermocouple measurement and output provide automatic and manual cold end temperature compensation.
13Can add new thermocouple, thermal resistance type according to customer needs.
DC24V Handheld Multifunction Process Calibrator For Site
Technical Indicators

(1)Measurement Index

Function Range Accuracy(% Reading+counts)
ZXTX-2025 ZXTX-1825
DC V 0~60.000V(Upper Display ±30V) 0.02%+2 0.05%+2
DC mA 0-24.000mA(Upper Display ±24mV) 0.02%+2 0.05%+2
DC mV -15.000mV~80.000mV 0.02%+2 0.05%+2
80.00mV~125.00mV

Resistance

(2 wires, 3wires)

 0.00Ω~440.00Ω 0.15Ω 0.25Ω
400..00Ω~3200.00Ω 1.0Ω 1.5Ω
Resistance (4wires) 0.00Ω~440.00Ω 0.1Ω 0.15Ω
400..00Ω~3200.00Ω 0.5Ω 1.0Ω
Frequency 1.000Hz~99.999Hz

0.01%+1

0.02%+1
1000.0Hz~9999.99Hz
10.000kHz~99.999kHz
TC J,K,T,E,R,S,B,N
RTD Pt100,Pt1000, Cu50, Cu100

(2)Output Index

Function Range Accuracy(% Reading+counts)
ZXTX-2025 ZXTX-1825
DC mA(Active/Passive) 0-24.000mA 0.02%+2 0.05%+2
DC V 0~10.000V 0.02%+2 0.05%+2
DC mV -15.000mV~99.999mV 0.02%+2 0.05%+2
100.00mV~125.00mV
Resistance 10.00Ω~440.00Ω 0.15Ω 0.25Ω
400.0Ω~3200.0Ω 1.0Ω 1.5Ω
Frequency 0.20Hz~200.00Hz

0.01%+1

0.02%+1
200.0Hz~2000.0Hz
2.000kHz~20.000kHz
TC J,K,T,E,R,S,B,N
RTD Pt100,Pt1000, Cu50, Cu100
