Rhombus Anti Glare Mesh Glass Reinforced Plastic Fence For Expressway / Railway
Rhombus Anti Glare Mesh Glass Reinforced Plastic Fence For Expressway / Railway
Specifications
Brand Name :
Jing Chuang
Place of Origin :
China
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
30000 Ton/Tons per Month
Delivery Time :
within 30 days
Packaging Details :
the band steel to fix the guardrail and post, use the wood box to contain the bolts nuts, washer
Technology :
Pultrusion
Application :
Highway , Road
Mesh Shape :
Rhombus
Mesh Specifications :
50*50mm ,40*80mm ,50*00mm, 75*150mm or customized
Name :
Anti Glare Fence
Description

Anti-Dazzle Net Of Glass Reinforced Plastic Fence For Expressway And Railway

Product introduction

Anti - dazzle net also known as anti - throw net, punch plate and so on.FRP is a special mechanical processing, the formation of mesh state of the tensile material object, can effectively ensure the continuity of anti-dazzle facilities and transverse view, but also can isolate the upper and lower lanes, to achieve the purpose of anti-dazzle and isolation, is a very effective highway protection products.

Specification

Tickness(mm) SWD(mm) LWD(mm) Wire stems width(mm) Width(m) Length(m) Weight(kg/m2)
0.5 2.5 4.5 0.5 0.5 1 1.8
0.5 10 25 0.5 0.6 2 0.73
0.6 10 25 1 0.6 2 1
0.8 10 25 1 0.6 2 1.25
1 10 25 1.1 0.6 2 1.77
1 15 40 1.5 2 4 1.85
1.2 10 25 1.1 2 4 2.21
1.2 15 40 1.5 2 4 2.3
1.5 15 40 1.5 1.8 4 2.77
1.5 23 60 2.6 2 3.6 2.77
2 18 50 2.1 2 4 3.69
2 22 60 2.6 2 4 3.69
3 40 80 3.8 2 4 5.00
4 50 100 4 2 2 11.15
