Inner Ear Loop Face Mask Machine For Hospital Surgical Face Mask Machine

This product is a full-automatic face mask production line, which realizes the entire automatic operation and simple operation. The whole process only needs 1-2 people to operate, and the labor cost is minimized. 6000-8000 masks can be produced per hour,. The production cost can be recovered after 7--15 days in 24-hour production.
Due to the large global demand and many orders, the delivery date needs to be determined after negotiation.

Usage:

Making 3 layer disposable mask for common use

Making 4 layer medical mask for hosiptal use

High Production:

100-120 PCS/Minute;

Production line:

Feeding--Molding--2 Station Separator-- 2 Ear Loop Machines

Delivery:

28 days after 40% downpayment

Function introduction :

This production line is a fully automatic one-to-two mask machine, one body machine drives two ear band machines. After the main body machine

outputs the mask body, the mask body sheet is conveyed to the turning mechanism by a conveyor belt structure. The reversing mechanism is used to flip the mask plate onto the belt connected to the ear band machine, and then the mask sheet is conveyed to the first mask plate on the front of the ear band machine through the conveyor belt, and finally the mask sheet is placed on the ear band by the cylinder pressing In the mask plate of the machine, the ear band machine is used to complete the welding of the ear bands of the mask and the edging, thereby completing the production of an ear band mask product. This machine adopts PLC, touch screen control, single-phase motor for main conveyor belt, stepping motor turning, precise transmission, stable control and adjustable speed.

Product Features

1. High stability, low failure rate, beautiful appearance without rust;

2. Computer PLC programming control, servo drive, high degree of automation;

3. Photoelectric detection of raw materials to avoid mistakes and reduce waste.

The technical parameters

1. Machine size length, width, and height: the whole machine has a size of 4500mm × 5500mm × 1830mmmm;

2. Voltage: AC220V 50-60HZ

3. One-to-two production line efficiency: 100-120 tablets / min

4. Power: 8.5KW

The Main Electrical Parts Main Machine Configuration:

1.Variable frequency motor

2. Ultrasound 2 sets

3. plc control 1 set

4. 2 sets of electronic eyes Ear strap machine configuration: 1. 2 sets of variable frequency motors
