Metal Steel Fireproof Roller Shutter Door Roll Forming Machine 10 - 20m/min Speed
Metal Steel Fireproof Roller Shutter Door Roll Forming Machine 10 - 20m/min Speed
Metal Steel Fireproof Roller Shutter Door Roll Forming Machine 10 - 20m/min Speed
Metal Steel Fireproof Roller Shutter Door Roll Forming Machine 10 - 20m/min Speed
Metal Steel Fireproof Roller Shutter Door Roll Forming Machine 10 - 20m/min Speed
Metal Steel Fireproof Roller Shutter Door Roll Forming Machine 10 - 20m/min Speed
Metal Steel Fireproof Roller Shutter Door Roll Forming Machine 10 - 20m/min Speed
Metal Steel Fireproof Roller Shutter Door Roll Forming Machine 10 - 20m/min Speed
Specifications
Brand Name :
YBT
Model Number :
YT233121
Certification :
CE ISO SGS
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
10 sets per month
Delivery Time :
45-60 days
Packaging Details :
Standard export packing with each machine tied and protected in container
Name :
fireproof shutter door roll forming machine
Thickness :
0.3-1.2 mm
Speed :
10-20 m/min
Color :
Customer's Requirement
Cutter Standard :
GCr12
Weight :
About 2.5T
Description

10-20m/min Metal steel fireproof roller shutter door roll forming making machine

Equipment components:
Man-made uncoiler, Roll forming machine, computer control system, hydraulic control system, cutting
Our products are widely used in various industrial factory, civilian building, warehouse and easy steel building manufacturing, and have features such as nice appearance and durable.

Echnical parameters

Name
metal steel fireproof roller shutter door frame cold making production line/Slide shutter door machine
Suitable to process
Color steel plate, galvanized sheet, aluminum coils and etc.
Width of the feeding material
100-160mm
Roller station
10-15 rows
Thickness of feeding material
0.3-1.2mm
Power Supply
380V, 3-Phase,50Hz
Productivity
10-20m/min
Rollers' material
45# steel
Diameter of shaft
75mm
Roller Diameter
50mm
Wall thickness of main forming machine
14mm steel plate
Main forming machine body
300 mm H steel
Motor power
4+3kw
Cutter Standard
GCr12
Size
7500*1500*1600mm
Weight
About 2.5T
Custom
According to customer's requirements

Product Technical Parameter

A. Manual Decoiler

(1) Max Width: 1250mm

(2) Inner Diameter: 500mm

(3) Outer Diameter: 1200mm

(4) Max Weight Capacity: 5T

B. Roll Forming

(1) Raw Material: Colored steel or galvanized steel

(2) Material Thickness: 0.8-2.2mm

(3) Working Speed: 12-15m/min; Adjustable

(4) Rollers: 20 rollers ( based on drawing )

(5) Material for Rollers: GCr15, polished, heated, quenched HRC55-60°

(6) Motor Power: 7.5KW

(7) Roller Diameter: 76mm

(8) Machine Side Plate Type: Guide Pin Type

(9) Transmission Type: Chain Transmission

(10) Finished Sheet Product as Stipulation: GB/T 12755-91

C. Hydraulic Cutting

(1) Cutting Type: Hydraulic, automatic cutting

(2) Blade Material: Cr12 with polished, heated, quenched HRC 60-62

(3) Power: 3KW

D. Control System

(1) Electrical Control: PLC Frequency Control System with touch screen

(2) Voltage: 380V/3Ph/50Hz(or as your local standard)

(3) Length Error: ±1mm

E. Output Table

(1) It is simple and used to load finished product

(2) Length: 4m

Metal Steel Fireproof Roller Shutter Door Roll Forming Machine 10 - 20m/min Speed

Packaging & Delivery
1. one 20-40ft container for loading one set machine with manual decoiler;
2. the whole Wiped Anti Rust Oil, PLC controller covered by foam film;
3. Spare parts and some small parts packed in plastic tooling box;
4. All Components Fixed by steel wire with Container.

Metal Steel Fireproof Roller Shutter Door Roll Forming Machine 10 - 20m/min Speed
