Specifications
Brand Name :
YBT
Model Number :
YT983408
Certification :
CE ISO SGS
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
10set
Delivery Time :
60-90 days
Packaging Details :
Standard export packing with each machine tied and protected in container
Name :
PU Sandwich
Voltage :
As Your Requirment or 380v, 60Hz, 3 phase or
Advantage :
Use Widely
Warranty :
1 Year
Sheet Thickness :
0.3-0.7mm
Control system :
PLC
Material :
Steel, metal panel sandwich line production
Description

Professional PU Sandwich Panel Machine Double Conveyor Belt Sewing Making Machine


The PU Sandwich Panel Production Line mainly consists of the two sets of Uncoiler, Steel Panel Transverse Cutting Machine, Steel Panel Surface PVC Film covering device, Roll forming machine (3 sets) and Platform (up and down), Pre-heating room, PU injecting section for foaming, Panel automatically cutting system and Cooling system conveyer, Automatic stacking machine;

The facing material of this panel can be PPGI, Aluminum foil, PVC sheets, etc and the core materials can be Polyurethane, Mineral Wool, Glass Wool, PIR, Phenolic or EPS.
Panel shape can be tailor-made according to customer's detailed requirements.

1 . Technical Parameter

Panel Material : 1. Type :Pre-painted steel; Aluminum; Platinum
2. Thickness :0.5-15 mm
3. Coil width :≤1250mm
4. Coil ID :508mm
5. Coil Weight : 5ton.7.5ton

Density 40-45kg/m3
The thermal conductivity 0.019-0.023W/M.K
Moisture permeability coefficient ≤3.34Ng/Pa/m.s
Water absorption ≤0.5g/100cm2
Enclosed rate ≥97%
The compression strength ≥220KPa
The bending strength ≥2450KN/m2
Oxygen index ≥28
Fire proof B1
Dimensional stability ≤1%
Application temperature -50℃-150℃
Exterior Steel thickness 0.4-0.7mm
Interior steel thickness 0.4-0.7mm
Core material thickness 40/50/60/75/100/120/150/200mm
Length Less than 11.8m
Effective width Wall panel:400-1120mm;Roof panel:1000mm
Grace finish Embossment,small wave,big rib,flat finish
Advantage Heat Insulation, light weight, quick installation,waterproof, fireproof, soundproof, energy-saving,environmental friendly,
Usage Various roofs and walls referring to the large size factory building ,workshop,coldstorage,villas,

2 . Main Component of line
Main roll former
1 . Un-coiler (5 tons ) 2 sets
2 . Embossing and firm machine 2 sets
3 .Automatic feeder and leveler (N.C) 1 sets
4 .Press machine 1 sets
5 .Square mould : 1 sets
6 .Upper roll former : 1 sets

7 . Mark machine (N.C) :1 sets
8 .Down panel roll former : 2 sets
9 .Double layer construction platform :1sets
10 .Double bridge device and conveyor : 1sets
11 .Other conveyor :1sets
12 .Hydraulic system :1sets
13 .Electrical control system :1sets

Pre-Heating system

1 .Heating house :1sets
2 .Pre-heating system: 1sets
3 .Electrical control system: 1sets

High Pressure foam Machine
1 .High pressure continuous foam machine :1sets
2 .Pursing output device :1sets
3 .Electrical control system :1sets

Drawing of PU Sandwich
Rock Wool PU Sandwich Panel Machine Double Conveyor Belt Sewing Making


3 . Simple PU Formed Sectional Sandwich Panel Production Line
Rock Wool PU Sandwich Panel Machine Double Conveyor Belt Sewing Making

Thickness of sandwich panel Application temperature
50mm Temperature 5°C or above
75mm Temperature -5°C or above
100mm Temperature -15°C or above
120mm Temperature -25°C or above
150mm Temperature -35°C or above
200 Temperature -45°C or above
