High Speed Truss H Beam Welding Line / Steel Bar Making Machine 20m Every Min
High Speed Truss H Beam Welding Line / Steel Bar Making Machine 20m Every Min
High Speed Truss H Beam Welding Line / Steel Bar Making Machine 20m Every Min
High Speed Truss H Beam Welding Line / Steel Bar Making Machine 20m Every Min
High Speed Truss H Beam Welding Line / Steel Bar Making Machine 20m Every Min
High Speed Truss H Beam Welding Line / Steel Bar Making Machine 20m Every Min
Specifications
Brand Name :
YBT
Model Number :
YT296647
Certification :
CE ISO SGS
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
3 sets per month
Delivery Time :
65-90 days
Packaging Details :
Standard export packing with each machine tied and protected in container
Name :
steel truss production line
Material :
steel
Power :
380V 50Hz
Max.speed :
20m/min
Air pressure :
0.6-0.8MPa
Warranty :
1 Year
Description

High speed truss welding machine steel bar making line 20m / min

This equipment is based on a substantial increase in steel template the stability of the welding machine, reduce the volume of machine, improve production efficiency is designed on the basis of the research and development, by roller conveyer, resistance welding machine (including the cooling system), control system and other parts, steel truss and galvanized sheet is mainly used in construction industry, iron plate, such as the welding of steel template, is used in the production of the auxiliary steel truss welding machine.The production process of the whole production line adopts the control mode combining part of manual and automatic: manually place steel formwork and truss and spot weld the first point, and then the pushing and welding of steel formwork and truss are all completed by the equipment automatically.

Technical Parameters:

No.

 Item Specification
1 Rated power 6*100KW
2 Power source 380V 50Hz
3 Phase number 3phase 4cable
4 Duty cycle 20%
5 Air pressure 0.6-0.8MPa
6 Coolant flow 40L/min
7 Coolant temperature ≤30°C
8 Dimension 32m*1.3m*2.0m
9 Max.speed 20m/min
10 Width of deck 576/600mm
11 Length of transmission rack 2*12m
12 Width of transmission rack 700mm
13 Speed of transmission 15m/min

High Speed Truss H Beam Welding Line / Steel Bar Making Machine 20m Every Min

Main features:

1 . Compact and reasonable structure, beautiful appearance.

2 . Single-row multi-point welding principle, fast welding speed, up to 20m/min.

3 . The process is simple, convenient and fast, saving labor costs and improving production efficiency.

4 . Three times of discharge, greatly reduce the impact on the power grid, to ensure the stability of product welding.

High Speed Truss H Beam Welding Line / Steel Bar Making Machine 20m Every Min
Finished products are as follow:

High Speed Truss H Beam Welding Line / Steel Bar Making Machine 20m Every Min


Service Commitment & Quality Assurance:
Installation: If necessary, engineer is available to service machinery overseas; but all the relevant cost and extra 100USD/day for our engineer will be paid by the buyer.

Warranty: 1 year since the machine leave seller's factory.
During the warranty period, it covers all spare parts of machines, if you find some spare parts were damaged, those new spare parts will be supplied free by us, but normal wear and tear excepted. And the freight should be bore equally by both parties.
