110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line
110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line
110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line
110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line
110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line
110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line
110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line
110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line
Specifications
Brand Name :
YBT
Model Number :
YB983459
Certification :
CE ISO SGS
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
10set
Delivery Time :
60-90 days
Packaging Details :
Standard export packing with each machine tied and protected in container
Name :
Steel Silo Roll Forming Machine
Voltage :
As Your Requirment or 380v, 60Hz, 3 phase or
Advantage :
Use Widely
Warranty :
12 Months
Thickness :
0.8-4.0mm
Material :
PI & PPGI
Description

110KW 1.5 - 4mm thickness Silo Roll Forming Machinery Transmission Table

The assembled silo that is composed of galvanized corrugated sheet is widely used for the purpose of commercial grain storage around the world, and our assembled silo corrugated sheet roll forming machine is especially designed to manufacture such steel sheets.

Specification of Ceiling Silo Roll Forming Machine

No Items Spec. Unit
1 Type of machine YX16-76.2-762
2 Structure Wall board type
3 Material PPGI
4 Feeding width 925 mm
5 Effective width 762/686 mm
6 Thickness 0.25-0.6 mm
7 Strength yield 550 Mpa
8 Working speed 16 m/min
9 roller step 18 Steps
10 Roller material 45# forged steel, hard chrome plating
11 Main shaft material 45# high quality steel, quenching treatment
12 Diameter of shaft 75 mm
13 Main motor power 7.5 KW
14 Hydraulic station power 3 KW
15 Hydraulic station pressure 12 Mpa
16 Voltage According to the customer requirements
17 Blade material Cr12 quenching treatment
18 Electric system Siemens PLC
19 Cut mode Hydraulic cutting, cutting after forming
20 Color of the machine Blue+Yellow
21 Container dimension 1x40 GP


Technological process:

Passive de-coiler ----- leveling and feeding ----- continuous hole punching ----- roll forming (without welding)----- positioning and cutting----- collection table

110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line

Application:

110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line

Packaging & Shipping

1 . Before loading to the container, we will check the machine first

2 .make some protection on the machine, such as, we will paint the coil on the roller and shaft, in case the roller and shaft got corrosion and rusty during long time delivery

3 .we will make the plastic package on the easy damage parts, and fix all the parts into container by the steel wire rope, and ensure the machine will not

4 .we will take photos for customer when loading to container.

Main product :

Roof roll forming machine

C and Z purlin roll forming machine

Downpipe roll forming machine

Hydraulic decoiler

Light keel roll forming machine6

Bending machine

Shearing machine

slitting machine

Roller shutter door roll forming machine

110KW Steel Silo Roll Forming Machine / Transmission Table Roll Forming Line

Features:

1 . The equipment control is PLC control, and multiple safety protection is set during normal production.
2 . The bed is welded with steel plates. It is also tempered to eliminate internal stress and avoid deformation of the fuselage.
3 . The forming frame is cast iron structure and tempered. High strength and long service life.
4 . The material of the roll shaft is 40Cr, and the hardness is HB280 after quenching and tempering treatment.
5 . The material of the forming mold is GCr15, quenching treatment, hardness: HRC 56-62 °C.
6 . The transmission structure is gearbox transmission. Each molding frame has a gearbox that guarantees time-out, high-intensity operation, and long service life.
