1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material
1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material
1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material
1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material
1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material
1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material
1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material
1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material
Specifications
Brand Name :
YBT
Model Number :
YT376506
Certification :
CE ISO SGS
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
10set
Delivery Time :
45-60 days
Packaging Details :
Standard export packing with each machine tied and protected in container
Name :
Cable Tray Roll Forming Machine
Material :
steel
Thickness :
1.0-2.5mm
Forming speed :
10-15m/min
Shafts diameter :
76mm
Warranty :
1 year
Description

1.0 - 2.5 mm Roll Forming Machine 18 forming stations for Cable Tray

Description:
Our cable tray forming machine has many advantages of stablity, efficiency, material saving, low noise. And our machines work within high speed which improves its productivity greatly. Besides, Its products have high quality and fashionable styles. It is widely used in stores, warehouses, buildings, welcomed by customers throughout the world. The machines can be designed to produce different shapes and sizes according to customer's requirements.

Technical parameters:

5 tons

hydraulic decoiler

Diameter: 420-560mm hydraulic expansion.

Expansion: Hydraulic decoiler
Capacity: 5000kg
Leveling device Roller: 5 rolls leveling
Main power: 5.5kw

Feeding device

Servo feeding motor: About 4.4KW
Punching press machine Press machine: 200tons
Punching mould material: Cr12mov
Main roll forming machine

Material thickness: 1.0-2.5mm
Raw material: Galvanized steel and black steel sheets
Forming speed: 10-15meters / min

Line speed: 4-6m/min
Forming stations: 18 stations
Material of roller: Gcr15, Quench HRC58-62 Plated Chrome
Material of shaft: 45# Steel

Shafts diameter: 76mm
Driven system: Chain driven
Main power: 22kw.

Hydraulic cutting system

Cutting power: 5.5kw

Material of blade: Cr12Mov, Quench HRC58-62

Length measuring: Automatic length measuring

Tolerance of length: +-1.5mm
Electrical control system Power supplier: 380V, 50 Hz, 3Phase (adjusted with the requirement)
Length & quantity measurement automatically;
Length & quantity controlled by PLC
Length inaccuracy can be amended easily.
Control panel: Button-type switch and touch screen
The language in the touch screen: English and Chinese

Working process:

Uncoiling---Leveling---Storage---Feeding---Punching---Cutting---Roll forming---Hydraulic cutting---Output table


1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material

Detailed information:

1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material

Main features:

Our standard cable tray roll forming machine uses cantilever type at the two sides, the punch press do the round ribs in bottom or different holes’stamping and cutting. The material is guided into main roll forming machine by guider. By plc control, automatically improve and adjust different width and height. Cable trays are used as an alternative to open wiring or electrical conduit systems, and are commonly used for cable management in commercial and industrial construction.

Finished products:

1.0 - 2.5 Mm Cable Tray Punching Machine 18 Forming Stations Steel Material

After-sale service:
1 . Installation and training of roof forming machine:
a . If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.

b . Without visiting, we will send you user manual and video to teach you to install and operate.

c . If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.

2 . After Service of roof forming machine:
a . One year guarantee for whole roof forming machine.
b . 24 hours technical support by email or calling
c . If there is any problem found of the roof forming machine, we will repair it for free in one year.

Main features:

Our standard cable tray roll forming machine produce cable tray width from 100 to 600mm, and height from 50 to 100mm, uses cantilever type at the two sides, the punch press do the round ribs in bottom or different holes’stamping and cutting. The material is guided into main roll forming machine by guider. By plc control, automatically improve and adjust different width and height. Cable trays are used as an alternative to open wiring or electrical conduit systems, and are commonly used for cable management in commercial and industrial construction.
