HW-CMM Connector, HW-M80-4611042,2mm Pitch.
HW-CMM Connector, HW-M80-4611042,2mm Pitch.
HW-CMM Connector, HW-M80-4611042,2mm Pitch.
HW-CMM Connector, HW-M80-4611042,2mm Pitch.
HW-CMM Connector, HW-M80-4611042,2mm Pitch.
HW-CMM Connector, HW-M80-4611042,2mm Pitch.
HW-CMM Connector, HW-M80-4611042,2mm Pitch.
HW-CMM Connector, HW-M80-4611042,2mm Pitch.
HW-CMM Connector, HW-M80-4611042,2mm Pitch.
HW-CMM Connector, HW-M80-4611042,2mm Pitch.
Specifications
Brand Name :
HIGH WOOD
Model Number :
HW-M80-4611042
Certification :
AS9001
Place of Origin :
China
MOQ :
100PCS
Price :
10＄--150＄
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100,000pcs per month
Delivery Time :
2--9 weeks
Packaging Details :
standard export package
P.C.LF CONTACTS(Male): :
Male:tail:copper alloy/Ni+Au flash 0,1µContact area:copper alloy/Ni+Au>1 µ
P.C.LF CONTACTS(Female): :
Body:copper alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ
MECHANICAL :
Mechanical operations:Up to 2500 cycles contact inssertion and withdrawal force:2 N max./0.2n min.oer ciontact Contact retention in insulator:10 n min Contact replacement in insulator:3 cycles
CRIMP LF CONTACTS: :
Male: Body:copper alloy/Ni+Au>1µ Female: Body:copper alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ
FIXING HARDARE: :
Jackscrew:Stainless steel Latch:Bertllium copper/plated nickel
INSULATOR: :
Special PPS UL 94-V0
Description

HW-M80-4611042:

The CMM has been developed for the aerospace,avionics,instrumentation & control,defence and transportation markets,with applications that induce IFES,HUDs,fight controls,FADEC units,radars,missiles, electro-optical sighting systems,satellites,mobile radios,power supplies,UAVs and engine controls.It is also used engine controls.It is also used in a growing number of medical,and telecom applications,NICOMATICs pecializes in the design,development and manufacture of electronic connectors.




Materials and coating:

Materials and coating
Insulation medium Glass fiber reinforced PPS,UL94-VO Radiation resistant,non hygroscopic,ozone resistant
Contact Copper alloy silver plated
Epiphy Stainless steel
Electrical performance index
electricity

25℃,Maximum 3A

85℃,Maximum 2.2A

contact resistance ≤25mΩ
Voltage withstand test(sea level) 800V AC/DC
Insulation resitance ≥500mΩ
Mechanical performance index
Mechanical life 500 times of plugging and unolugging
Environmental performance index
Operating ambient temperature -55℃ - 125℃

Product Details:

HW-CMM Connector, HW-M80-4611042,2mm Pitch.

HW-CMM Connector, HW-M80-4611042,2mm Pitch.

HW-CMM Connector, HW-M80-4611042,2mm Pitch.

HW-CMM Connector, HW-M80-4611042,2mm Pitch.

HW-CMM Connector, HW-M80-4611042,2mm Pitch.

Product display:


HW-CMM Connector, HW-M80-4611042,2mm Pitch.

HW-CMM Connector, HW-M80-4611042,2mm Pitch.

HW-CMM Connector, HW-M80-4611042,2mm Pitch.

HW-CMM Connector, HW-M80-4611042,2mm Pitch.
