SMA Series RF Coaxial Connector SMA-JB2
SMA Series RF Coaxial Connector SMA-JB2
SMA Series RF Coaxial Connector SMA-JB2
SMA Series RF Coaxial Connector SMA-JB2
SMA Series RF Coaxial Connector SMA-JB2
SMA Series RF Coaxial Connector SMA-JB2
SMA Series RF Coaxial Connector SMA-JB2
SMA Series RF Coaxial Connector SMA-JB2
Specifications
Brand Name :
HIGH WOOD
Model Number :
SMA-JB2
Certification :
AS9001
Place of Origin :
China
MOQ :
100pcs
Price :
10$-150$
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
100，000pcs per month
Delivery Time :
2-9weeks
Packaging Details :
Standard export package
Connector type :
SMA Series RF Coaxial Connector
Dielectric Withstand Voltage :
1000V
Ambient Temperature :
-55°C～+155°
Insulation Resistance :
≥5000MΩ
Center Conductor :
<3mΩ
Outer Conductor :
<2mΩ
Description

SMA Series RF Coaxial Connector SMA-JB2

Product introduction

It has the advantages of small size, wide frequency range, reliable mechanical and electrical performance, etc. It is currently the most widely used coaxial RF connector. b. Used in communications, aerospace, navigation, weapon systems and microwave measurement equipment and other fields

Product Display

SMA Series RF Coaxial Connector SMA-JB2


Main Technical Parameters

Frequency Range Insulation Resistance: ≥5000MΩ

With Flexible Cable 0～12.4GHz Working Voltage: 330V

Semi-Flexible Cable 0～18GHz Dielectric Withstand Voltage: 1000V

Ambient Temperature: -55°C～+155° Contact Resistance:

Characteristic Impedance: 50Ω Center Conductor: <3mΩ

Voltage Standing Wave Ratio Outer Conductor: <2mΩ

With Soft Cable: ≤1.15+0.02F Mechanical Life: 500 Plug And Unplug Times

With Semi-Rigid And Semi-Flexible Cables ≤1.10+0.02F

SMA Series RF Coaxial Connector SMA-JB2

Product pictures:

SMA Series RF Coaxial Connector SMA-JB2SMA Series RF Coaxial Connector SMA-JB2SMA Series RF Coaxial Connector SMA-JB2SMA Series RF Coaxial Connector SMA-JB2
