YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
Specifications
Brand Name :
HIGH WOOD
Model Number :
YW1-23F01S02
Certification :
AS9001
Place of Origin :
China
MOQ :
100pcs
Price :
10$-150$
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100，000pcs per month
Delivery Time :
2-9weeks
Packaging Details :
Standard export package
Description

YW1-23F01S02

Product Introduction:

YW series connector,rj45,Plug,Male,Bayonet Coupling,cable,solder,Socket,Female,Bayonet Coupling,panel mount,Solder cup,4 hole flange,Straight,Aluminum alloy,Electroless nickel plating,Male Butt-Joint Female.

Electrical Characteristics
Relative humidity: 92-98% at 40±2°C
Insulation resistance: ≥3000MΩ
Contact resistance: 1.5MΩ/3MΩ/5MΩ/7M
Rated voltage: 600V
Rated current: 3A / 5A / 10A / 25A


Mechanical Characteristics
Vibration: vibration frequency is 10Hz-2000Hz, acceleration 196 m/s2
Impact: acceleration 980.7 m/s2
Collision: 392 m/s2
Mechanical life: 500 times
Environmental Characteristics
Working temperature: -55 ° C ~ +125 ° C
Working pressure: 101.33kPa-1.33Pa
Air tightness: ordinary socket: no more than 6 × 10-2 PaL / s
Glass sintered socket: no more than 1×10-5 PaL/s


Material:
Shell: aluminum alloy
Insulator: thermoplastic material
Contact: copper alloy gold plating/nickel plating

Product pictures:


YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connectorYW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
YW series YW1-23F01S02 metal high-speed network electrical circular RJ45 connector
