HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.
HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.
HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.
HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.
HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.
HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.
HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.
HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.
Specifications
Brand Name :
HIGH WOOD
Model Number :
HW-222S30M11-2207086
Certification :
AS9001
Place of Origin :
China
MOQ :
100PCS
Price :
10＄--150＄
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100,000pcs per month
Delivery Time :
2--9 weeks
Packaging Details :
standard export package
P.C.LF CONTACTS(Male): :
Male:tail:copper alloy/Ni+Au flash 0,1µContact area:copper alloy/Ni+Au>1 µ
MECHANICAL :
Mechanical operations:Up to 2500 cycles contact inssertion and withdrawal force:2 N max./0.2n min.oer ciontact Contact retention in insulator:10 n min Contact replacement in insulator:3 cycles
INSULATOR: :
Special PPS UL 94-V0
CRIMP LF CONTACTS: :
Male: Body:copper alloy/Ni+Au>1µ Female: Body:copper alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ
P.C.LF CONTACTS(Female): :
Body:copper alloy/Ni+Au 0,2 µ Socket:berylliumcopper/Ni+Au>1,25 µ
FIXING HARDARE: :
Jackscrew:Stainless steel Latch:Bertllium copper/plated nickel
Description

HW-222S30M11

The CMM has been developed for the aerospace,avionics,instrumentation & control,defence and transportation markets,with applications that induce IFES,HUDs,fight controls,FADEC units,radars,missiles, electro-optical sighting systems,satellites,mobile radios,power supplies,UAVs and engine controls.It is also used engine controls.It is also used in a growing number of medical,and telecom applications,The CMM MICRO CONNECTOR interconnection system is a 2mm pitch connector (square matrix) witch proven high.




Part numbering:

HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.

TypeL
S24-28
C22


FIXING HARDWARE FOR CMM 220 FEMALE

REFERENCASSEMBLY ON PCBOVERALL DIMENSIONSRECOMMENDATION

M11

HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.

HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.

M11 :
CMM Female :
Y-YL-T-S-C-E
(D :straight)


MALE STRAIGHT ON CABLE P/N 30-33xx (solder or crimp)

LoadedUnloadedAmpereCable AØBØCLength D holeLength E bodyLength F conductorSolderCrimp by HX3 Hexagone size/DiesCrimp by AF8
AWG 20AWG 18AWG 16AWG 14AWG 12
330530-33055A× 1,1mm

1,65
mm

6,2mm6,7mm4,5mmOKHex.1,9 mm/C14923OK
330830-33088A × 1,35mm

1,85
mm

6,2mm6,7mm4,5mmOKHex.1,9 mm/C14923OK
331030-331010A××× 1,7mm 6,2mm6,7mm6mmOK OK
331530-331515A × 2mm 6,2mm6,7mm6mmOK OK
332030-332020A ×2,6mm 6,2mm6,7mm5,3mmOK OK


Ordering model:



HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.HW-CMM Connector, HW-222S30M11,MTL-55302F,2mm Pitch.
