Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM
Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM
Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM
Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM
Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM
Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM
Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM
Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM
Specifications
Brand Name :
HIGH WOOD
Model Number :
J30JHJ9ZK00D01 L=300MM
Certification :
AS9001
Place of Origin :
China
MOQ :
100PCS
Price :
10＄--150＄
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100,000pcs per month
Delivery Time :
2--9 weeks
Packaging Details :
standard export package
Ambient :
-55 ~ +125°C
Relative :
+40°C attain 95%
Vibrate :
10~ 2000Hz 294m/s2
Mediator resistant oneself :
800V
Mechanical life :
500
Salt fog time :
96h
Description

Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM

  • Number of cores: 9,15,21,25,31,37, A51,51,69,100 cores have ten specififica.
  • Use stranded elastic needle (twist needle) with high contact density.
  • The tail end form has the swing line type, the welding cup type, the straight insert printed plate type.
  • The products are small in size, light in weight, high contact density and high serializatn
  • The locking components of this family of products shall be assembled together with the order requirements.
  • If not necessary, the locking components shall be indicated in the contract.
  • The product performance meets the requirements of the GJB2446.
  • Implementation Standard: Q / FY QJ0022-2016 Detailed Specifification for J30JHT Series
  • Micro Rectangular Electrical Connectors.




Part numbering

Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM

1 Principal:J30J

2 Shell structure and materials:Electroless nickel plating on aluminum alloy,Casing flflange hole diameter (9-69 core is 02.31,100 core is 3.7)

3 Number of contacts:9,15,21,25,31,37,A51,51,69 ,100

4 Connector and contact parts type:TJ- Plug insert pin; ZK- Socket with jack
5 Form of the end of the contact:
Type I: 00- Sling type, crimping wire wire gauge AWG26 (wire brand, length on demand)
CA- Sling type, crimped C55/0112-26 conductor, sling length 450mm.
CB- Sling type, crimped C55/0112-26 conductor, sling length 900mm.
Type II: SA- welding cup type
ND -- In-line printed board, pin length 2.77mm,9-37 core spacing 2.54mm
x row spacing 1.91mm. 51-100 core spacing 1.91mm x 1.91mm.
ND -- In-line printed board, pin length 3.56mm,9-37 core spacing 2.54mm
x row spacing 1.91mm. 51-100 core spacing 1.91mm x 1.91mm.
ND -- In-line printed board, pin length 4.37mm,9-37 core spacing 2.54mm
x row spacing 1.91mm. 51-100 core spacing 1.91mm x 1.91mm.
6 Type of locking component:
000- without locking assembly;
Type B - Free end locking assembly, thread #2-56UNC-2A, 100 cores for 9-69 cores
Use thread #4-40UNC-2A (refer to locking attachment in product family tree);
Type N - Free end locking assembly, thread #2-56UNC-2B, 100 cores for 9-69 cores
Use thread #4-40UNC-2B (refer to locking attachment in product family tree);
7 Tail cover accessories Category:
Type I: Not indicated - without tail cover attachment
Type II: With plastic tail cover attachment
SF has been inserted into the printed board, 9, 15, 21, 25, 31, 37 core pins for 4 rows.
Type III: Accessories with metal tail cover (see product pedigree for details)
8 Plastic tail Cover Type:
Unsympathetic - No plastic tail cover
Type K - Through hole for mounting of tail cover (in-line printed board only)

MAIN TECHNICAL FEATURES

Ambient

-55 ~ +125°C

Contactresistance

≤ 10Ω

Relative

+40°C attain 95%

Insulation resistance

≥5000 Ω

Vibrate

10~ 2000Hz 294m/s2

Mediator resistant oneself

 800V

Lash

980m/s2

Mechanical life

 500

Accelerated

 735m/s2

Instantaneous time

≤1μs

Rated

current

 3A

Salt fog time

 96h


CONTACT ARRANGEMENT (FROM THE BUTT END)

Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MM


Product showing

Rectangular Electrical Connector J30JHJ9ZK00D01 L=300MMRectangular Electrical Connector J30JHJ9ZK00D01 L=300MMRectangular Electrical Connector J30JHJ9ZK00D01 L=300MMRectangular Electrical Connector J30JHJ9ZK00D01 L=300MM
