HR-60Z / HR-90Z High Shear Homogenizer Digital Display Mode Pilot For Food Industry
HR-60Z / HR-90Z High Shear Homogenizer Digital Display Mode Pilot For Food Industry
HR-60Z / HR-90Z High Shear Homogenizer Digital Display Mode Pilot For Food Industry
HR-60Z / HR-90Z High Shear Homogenizer Digital Display Mode Pilot For Food Industry
HR-60Z / HR-90Z High Shear Homogenizer Digital Display Mode Pilot For Food Industry
HR-60Z / HR-90Z High Shear Homogenizer Digital Display Mode Pilot For Food Industry
Specifications
Brand Name :
HiYi
Model Number :
HR-60Z/HR-90Z
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
15 work days
Packaging Details :
paper case
Model :
HR-60Z/HR-90Z
Voltage :
220V/50HZ
Speed Mode :
Digital
Lifting mode :
Electro-hydraulic
Viscosity(mpas) :
8000
Sample touch material :
SS316L
Description

Pilot High Shear Dispersing Homogenizer
HR-60Z/HR-90Z

OVERVIEW

The pilot scale high-shear dispersing emulsifier is designed for pilot-scale, simulated production and small batch production in factories. The working head has a high-speed rotating rotor and a precise stator working cavity to generate strong hydraulic shear by high linear speed. Centrifugal extrusion, high-speed cutting and collision make the materials fully dispersed, emulsified, homogenized, crushed and mixed, and finally stable and qualified products are obtained.

FEATURES & BENEFITS

● A variety of working heads are available to meet different needs;

● Rotation speed uses frequency conversion speed regulation, digital display mode, the lowest can reach 50rpm;

● Electric hydraulic lifting mode, simple operation and convenient use;

● The high-speed variable frequency motor realizes the function of variable frequency start protection, which meets the requirements of continuous work in the experiment;

● The instrument is equipped with a red mushroom head emergency stop button；

● When the machine is in a fault state, use this button to cut off the power supply, so that the equipment will stop running immediately to protect the safety of people and equipment;

APPLIATION

Wide range of applications: different grades of fine chemicals, petrochemicals, pesticides and fertilizers, biomedicine, medical chemicals, food industry, etc.

HR-60Z / HR-90Z High Shear Homogenizer Digital Display Mode Pilot For Food Industry

SPECIFICATIONS

Model
HR-60Z
HR-90Z
Item No
1004012001
1004013001
Voltage
220V/50Hz
220V/50Hz
Motor Power/Total Power
0.75/1
1.5/2
Capacity(ml)
5-30
10-50
Viscosity(mpas)
8000
8000
Speed Range(rpm)
0-6000
0-3200
Speed Mode
Digital
Digital
Speed Control
Speed regulation
Speed regulation
Sample touch material
SS316L
SS316L
Bearing working head
PTFE
PTFE
Standard working head
60G
90G
Working Support Material
316L
316L
Lifting mode
Electro-hydraulic
Electro-hydraulic
Lifting distance(mm)
350
350
Packing material
Wooden packing
Wooden packing
Exterior Dimension(mm)
700*700*1050
800*800*1100
Packing Dimension(mm)
800*800*1250
900*900*1280

HR-60Z / HR-90Z High Shear Homogenizer Digital Display Mode Pilot For Food Industry
