KANE 958 Commercial Flue Gas Analyser With Direct CO O2 & CO Sensor Protection
KANE 958 Commercial Flue Gas Analyser With Direct CO O2 & CO Sensor Protection
KANE 958 Commercial Flue Gas Analyser With Direct CO O2 & CO Sensor Protection
KANE 958 Commercial Flue Gas Analyser With Direct CO O2 & CO Sensor Protection
Specifications
Brand Name :
HiYi
Model Number :
KANE958
Certification :
CE
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Packaging Details :
paper case
Temperatures :
0 - 45°C
Pump :
Inner pump
Size :
216mm x 105mm x 45mm
Weight :
Approx. 0.625g
Type :
Portable Gas Detector
Description
KANE958 Commercial Analyser
Flue Gas Analyser with direct CO O2 & CO sensor protection

OVERVIEW


Tests domestic, commercial & industrial boilers up to 5 MW
Latest upgradeable sensor technology
Easy to use rotary dial
Purge pump protection prevents accidental damage to CO sensor
Wireless as standard
Wirelessly connect to optional KANE LINK enabled devices
Hydrogen (H2) ready – up to 20% blend
MCERTS (pending) compatible with optional KANE GCU Gas Chiller Unit

FEATURES


* Rotary dial & 6 line display
* Data hold, log & print with user details to optional printer
* Combustion - Pressure - Temperature
* Worklight
* Backed by KANE CARE - We promise to never let you down or your money back

* Install & service domestic oil & gas appliances

additional sensors to suit applications
* Commission & service industrial & marine boilers & engines
* Safety checks – CO in rooms or around appliances
* Combustion performance checks
* Combustion efficiency checks
* Flue Draught


* Natural Gas
* LPG
* Coke
* Butane
* Light oil
* Propane
* Biogas
* Heavy oil
* Coal
* Wood pellets

SPECIFICATION
PARAMETER
RANGE
RESOLUTION
ACCURACY
Temperature Measurement
Flue Temperature
0 - 600°C
0.1°C
±0.5°C
Inlet temperature (Internal Sensor)
0 50°C
0.1°C
±1°C
Inlet temperature (External Sensor)
0 - 600°C
0.1°C
±0.5°C
Flue Gas Measurement
Carbon Monoxide
0 - 2000ppm
1ppm
±3ppm or ±5% of reading (whichever is greater)
Oxygen
0 - 21%
0.10%
±0.3% Volume
Calculations
Carbon Dioxide
0 - 20%
0.10%
±0.3% Volume
CO/CO2 Ratio
0 - 0.9999
0.0001
±5% of reading
Efficiency (Net or Gross)
0 - 99.9%
0.10%
±1% of reading
Efficiency High (C)
0 - 119.9%
0.10%
±1% of reading
Excess Air
0 - 119.9%
0.10%
±0.2% of reading
Pre-programmed Fuels
UK, USA & France
Natural Gas, Propane, Butane, LPG, Light Oil, Digester Gas, Wood Pellets Heavy Oil
European
Natural Gas, Light Oil, Bio Oil, Coke, LPG, Wood, Town Gas, Butane & Propane
Battery Life
>8 hours (continuous with pump on)
Certification
The KANE458s is independently tested & certified to EN 50379, Parts 1-3 in accordance to 1st German Federal Emission Control
Ordinance (Bim5chV)
Operating Conditions
Temperatures
0 - 45°C
Humidity
15 to 90% RH, (non-condensing)
Power Supply
Rechargeable batteries, USB Charging
Physical Characteristics
Weight
Approx. 0.625g
Dimensions
216mm x 105mm x 45mm
