Micro mini 0ms low latency ethernet video transceiver for UAV surveillance
Micro mini 0ms low latency ethernet video transceiver for UAV surveillance
Micro mini 0ms low latency ethernet video transceiver for UAV surveillance
Micro mini 0ms low latency ethernet video transceiver for UAV surveillance
Specifications
Brand Name :
IFLY
Model Number :
FIP-2420
Certification :
CE, FCC, RoHS
Place of Origin :
China
MOQ :
1 set/box
Payment Terms :
T/T, Western Union
Supply Ability :
1500 set/month
Delivery Time :
3-5 Days
Modulation :
TDD-COFDM
Duplex Data :
TTL/SBUS/PPM/RS232/MAVLINK
Antenna :
Double Antenna For TX And RX
Video Out :
Ethernet
Contorl System: :
Pixhawk
Latency :
No Latency
Distance :
18-22km
Color :
Black And Silver
Description

Micro mini 0ms low latency ethernet video transceiver for UAV surveillance

Introduction

IFLY HD is a professional Wireless full HD transmitter for UAV drone applications that need an high quality full HD video and duplex data transmission with strong signal and long range. Designed from the ground up for UAVdrone applications, IFLY packs the performance, form factor, interfaces and reliability required for industrial applications.

Industrial and professional applications now share the same requirement, a robust wireless HD video downlink and data uplink and downlink and long range transmission. IFLY, delivers excellent HD image quality, low latency, and the highest levels of robustness. IFLY it’s 2.4GHz radio, double antennas design and software channel selection ensures resilient connectivity, free from interference, specifically from UAV controls.

Feature:

1) COFDM modulation, Stable transmission
2) Support high speed moving transmission
3) Works well with Pixhawk system
4) Great security by encryption of AES128 bits
5) Modular design, compact structure, OEM design
6) Support custom made for you or add additional functionality.

Transmitter system Receiver system
Size: 76*73*24mm Size: 68mm*48mm*15mm
Weight:146g Weight: 68g
Power Interface: DC12V/0.66A Power Input: DC12V/0.33A
Power Consumption: 8Watts Power Consumption: 5Watts

Package included 1 x Transmitter
1 x Receiver
2 x TX Antenna
2 x RX Antenna
4 x TTL cable
1 x RS232 Cable
1 x T33 cable for pixhawk
2 x LAN Cable
4 x Power Cable
