30km 2.4GHz Long Range UAV COFDM Transmitter Duplex Mavlink Data System
30km 2.4GHz Long Range UAV COFDM Transmitter Duplex Mavlink Data System
Specifications
Brand Name :
IFLY
Model Number :
FIM-2430
Place of Origin :
CHINA
MOQ :
1SET
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1SET
Delivery Time :
5-8DAYS
Packaging Details :
Standard exporting package
Working Temperature :
-40℃~+85℃
Video Input :
HDMI and IP
Fly Controller :
PIXHAWK
Software :
for video local save
Video output :
PC and Monitor simultaneously
Double Serial ports :
bi-directional data
Baud rate :
115200bps(adjustable)
Description

30km 2.4GHz Long Range UAV COFDM Transmitter Duplex Mavlink Data System

The IFLY HD Video Downlink features wireless full 1080p 60fps HD transmission with zero latency.
FNS-8408 by IFLY is an innovative Wireless HD link for professional UAV drone applications. Leveraging IFLY’s leadership in the wireless video market, FIM-2430 brings broadcast HD video quality and robustness standards to the rapidly evolving UAV aerial video arena.

Main Features:

  • Frequency: 2.4GHZ(2.400-2.482GHz)
  • Ultra-high Resolution Image: Independently developed CABAC (h.264+h.265) coding&decoding technology
  • Video: Video sources self-adaptive(Max 1080P), Support HDMI Input/output
  • Ultra-distance: 30km(ST30HPT)
  • Transmission Signal: Support SBUS(Futaba)/PPM/TTL/RS232/485
  • Support Video and Duplex Data (Compatible with different brand Fly control system and RC in the market)
  • TTL bidirectional serial port
  • Ultra-low Delay: ≤12-25ms
  • 100Mbps Ethernet for option
  • Output Video to PC and monitor display simultaneously.
  • Working Temperature: -40℃~+85℃

Applications

  • Aerial video production and cinematography
  • Real-time HD FPV piloting
  • Industrial and commercial inspection
  • Surveillance and security
  • Real estate assessment and supervision
  • Search and rescue
  • First responder situation evaluation
  • Crowd control
  • UAV enthusiast recreation
  • Enhances law enforcement, emergency and critical infrastructure operations
Frequency 2.4GHz(2.402-2.482GHz)
Error Detection LDPC FEC/Video H.264/265 Super Error Correction
RF Transmitted Power 33dbm
Power Consumption TX: 19Watts/RX: 8Watts
Distance

25-35km

(Notes:True distance is related to the environment)
Bandwidth 4/8MHz
Antenna

1T: Omnidirectional Antennas

1R: Omnidirectional Antennas or Panel Antenna
Video Input/output On board HDMI mini TX/RX or FFC convert to HDMI-A TX/RX
Video Color Space Default 4:2:0
Video Compressed AVC adds H.265 feature TS stream
Encryption AES128
Transmission Mode point to point
Start-up time 25s
Re-connection time Less than 1s after signal has been recovered
End to End Latency 50-70ms for1080P60/720P60 Encoding and decoding
Transmission Rate 3/6Mbps
Receive Sensitivity -98dbm@4Mhz
-95dbm@8Mhz
Two-way function Support video and duplex data simultaneously
Data Support TTL/MAVLINK/Telemetry
Interface 1080P/60 HDMI Mini ×1
Antenna ×1
S1 TTL bidirectional serial port ×1

RS 232 bidirectional serial port ×1

(RS 232 and S1 TTL serial port cannot be used at same time)
Ethernet to RJ45 on Windows ×1
Power Input ×1
Indicator Light HDMI input/output Status(WL Light)
Signal Strength Indicator( 1, 2, 3)
Connection Status Indicator(5, 6)
Video circuit board Work Indicator(4)
Power light
HDMI HDMI mini/Flexible Flat Cable(FFC)
Metal Case Design CNC technology
Double aluminum alloy shell
Conductive anodizing craft
Power supply DC7- 18V (DC12V advised)
Temperature Range Operating temperature: -40°C ~+85°C
Storage temperature: -55°C ~ +85°C
Dimension Tx/Rx: 74.6×72.9x22.5mm
Weight Tx/Rx 146g

30km 2.4GHz Long Range UAV COFDM Transmitter Duplex Mavlink Data System

Secure wireless data link, ideal for long-range UAV missions
