2.3Ghz Full Duplex TDD-COFDM 50km Digital Video Transceiver Wireless Unmanned Aircraft UAS
2.3Ghz Full Duplex TDD-COFDM 50km Digital Video Transceiver Wireless Unmanned Aircraft UAS
Specifications
Brand Name :
IFLY
Model Number :
FIM-2450
Place of Origin :
CHINA
MOQ :
1SET
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
1SET
Delivery Time :
5-8DAYS
Packaging Details :
Standard exporting package
Frequency :
2.3Ghz/2.4Ghz/2.5Ghz
Ethernet :
TCP/IP/UDP
Fly Controller :
PIXHAWK
Serial Ports :
Bi-directional Data Transmission
Ethernet port :
1*100Mbps
Transmit Range :
50km
Baud rate :
115200bps(adjustable)
Data Rate :
1.5/3/6Mbps
Description

2.3Ghz Full Duplex TDD-COFDM 50km Digital Video Transceiver Wireless Unmanned Aircraft UAS

IFLY is a leading developer of innovative wireless communications and information systems for both military and commercial applications. Our advanced video and data link systems are ideal for critical communications in tactical unmanned systems such as unmanned aerial vehicles (UAVs, UAS, drones, RPAS), unmanned ground vehicles (UGVs) and unmanned surface vehicles (USVs), and are designed with portability and reliability foremost in mind.

Frequency Option

  • 2.3Ghz
  • 2.4Ghz
  • 2.5Ghz

Key Features

  • Video Input Interface: HDMI
  • Ethernet: Support TCP/IP/UDP
  • 2* Serial Ports: Bi-directional Data Transmission
  • 2* Antennas: Dual Tx antenna and Dual Rx antenna
  • 1*100Mbps Ethernet port
  • Output Video to PC and Monitor Simultaneously

Specification

Frequency 2.3Ghz 2304 ~ 2390 MHz
2.4Ghz 2402~2482 MHz
2.5Ghz 2500~2570 MHz
Bandwidth 2/4/8MHz
RF Power 2W (Bi-Amp, 2W Peak Power of each power amplifier)
Transmit Range 50km
Transmit Rate

1.5/3/6Mbps (Video code stream and serial data)

The best video stream: 2.5Mbps
Baud Rate 115200(Adjustable)
Rx Sensitivity -100/-95/-90dbm
Wireless Fault Tolerance Algorithm Wireless baseband FEC forward error correction / video codec super error correction
Video Latency

Latency for encoding + transmission + decoding

720P/60 <50 ms

1080P/60 <80ms
Link Rebuild Time <1s
Modulation Uplink QPSK/Downlink QPSK
Video Compression Format H.264
Video Color Space 4:2:0 (Option 4:2:2)
Encryption AES128
Start Time 25s
Power DC-12V (10～18V)
Interface

Interfaces on Tx and Rx are same

  • Video input/Output: Mini HDMI×1
  • Power Input Interface×1
  • Antenna Interface: SMA×2
  • Serial×2: (Voltage:+-13V(RS232), 0~3.3V(TTL)
  • Ethernet: 100Mbps x 1
Indicators
  • Power
  • Tx and Rx Status Indicator
  • Tx and Rx Working Indicator
  • Ethernet Working Indicator
Power Consumption

Tx: 17W(Max)

Rx: 6W
Temperature

Working: -40 ~+ 85℃

Storage: -55 ~+85℃
Dimension Tx/Rx: 73.8 x 54 x 31 mm
Weight Tx/Rx: 160g
Metal Case Design CNC Technology
Double Aluminum Alloy Shell
Conductive anodizing craft

2.3Ghz Full Duplex TDD-COFDM 50km Digital Video Transceiver Wireless Unmanned Aircraft UAS

Mini secure wireless data link for miniature and micro-drones
