Powered by an Intel Celeron J1900 processor with 4 cores and 4 threads, up to 2.42 GHz, 2 MB of L2 cache, and a total power consumption of only 10 W. This mini PC is compact and powerful.
It has an all-aluminum fins fanless cooling design. Due to the large cooling area, it completely eliminates fan noise and provides a quiet working environment. In addition, with no fan, there is no dust inside the machine, greatly extending the life of the hardware and improving the overall stability of the device.
It also provides the platform with 7*24 hour 24/7 operation capability, ensuring a stable operating environment at all times. You can set it up with boot-up and WOL settings to provide convenience and flexibility for your business or personal needs.
Whether it's an industrial application or a home office solution, this mini PC is ideal for those who demand the highest levels of performance and reliability.
CPU | Intel Celeron J1900 4 Cores 4 Threads Processor, Burst Frequency 2.42 GHz, 2 MB L2 Cache, 10W TDP |
CPU | Intel® HD Graphics for Intel Atom® Processor Z3700 Series |
Memory | 1*DDR3L SO-DIMM, Max up to 8GB |
Storage (Hard Disk) | 1*MSATA SSD, 1*2.5 inch SATA HDD/SSD |
Ethernet | 2*GbE RJ45 Intel i211/i210 LAN |
Video Support | 1*HDMI,1*VGA |
I/O Interface | 2*USB3.0, 4*USB2.0, 6*DB9 COM(COM1/2 support RS485/RS422), 1*HDMI, 1*VGA, 10*GPIO(Custom In/Outputs), 1*Power Button: 12V Power in, 1*Audio, 1*Mic, 2*Antenna port for WIFI/3G/4G |
Expansion | 1*Mini-PCIE (support WIFI/Bluetooth); 1*Mini-PCIE (with SIM slot, support 3G/4G module, WIFI/Bluetooth) |
OS | Windows 7/8/10, Linux, WES7/10, etc. |
Other | Supports Watchdog, Auto Power on, PXE boot |
Cooling System | Fanless Cooling |
Power | 1*DC 12V 3A |
Material | Aluminium Alloy |
Suitable Temperature | Operating Temperature: -20℃ to +60℃; Storage Temperature: -30℃ to +70℃; Storage Humidity: 10% - 90%@30℃ (Non-condesing) |
Dimension | 180*120*54mm |
Weight | About 1.0kg |
Installation | Supports Desktop/ Wall-mounting |
Powered by an Intel Celeron J1900 processor with 4 cores and 4 threads, up to 2.42 GHz, 2 MB of L2 cache, and a total power consumption of only 10 W. This mini PC is compact and powerful.
This industrial fanless PC powered by 1*DDR3L SO-DIMM, Max up to 8GB and 1*MSATA SSD, 1*2.5 inch SATA HDD / SSD, which significantly improves computer responsiveness, instant program initiation and seamless file upload / download.
Enclosed construction ensures robust machine operation against diverse dusty industrial surroundings with broad temperature range (-20℃ to +60℃) and exceptional levels of corrosion and moisture resistance.
With Gigabit Ethernet port * 2, COM port * 6, GPIO * 1, USB3.0 * 4, USB2.0 * 2, VGA * 1, HDMI * 1, can be flexibly expanded to control more external devices.
