GCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN Protocol
GCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN Protocol
GCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN Protocol
GCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN Protocol
Specifications
Brand Name :
GCE
Model Number :
RBMS07S23-50A288V
Certification :
CE UL
Place of Origin :
china
MOQ :
2
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10000+pcs+1 month
Delivery Time :
8-15 days
Packaging Details :
Corrugated Carton,510*310*210mm
Votage :
0-288V
color :
black
Communication :
CAN, RS485,LAN
current :
-50--50A
Application :
Solar, Wind, UPS, EV Car,Home Appliances,Boats,Energy storage system
Description

GCE 90s 288V 50A High Voltage Relay Solution Master Slave BMS with 15s BMU for LFP NMC LTO BESS UPS EV PCBA Contactor

    • 288V50Amp

Communication protocol:
Rs485, CAN, LAN, Dry contact

* 2U standard 19inch case * Efficient, stable and reliable * size:W440*H88*D500mm

GCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN Protocol

GCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN ProtocolGCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN ProtocolGCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN Protocol

Accessories

12S-24S BMU(Slave)

12S-24S BMU has 8pcs of tempreture sensors, Fan voltage 48V(17S-24S 12V), voltage detection range 0-5V,12V power
supply,consumption less 20mA, CAN2.0 B communication

Wire harness-Signal acquisition wire

18 Pin+20Pin wire, standard length is 600mm,900mm,1200mmtempreture sensor wire: standard length is 600mm,900mm,1200mm
Fan wire: 600mm

Wire harness-communication wire

Communication wire is connecting from master BMS to each BMU with cascade connection, the last port is for terminal resistance
Specification
Product Name
BMS
Model no.
RBMS07S2-3-50A288V
protecting method
MCCB+Contactor
Rated Current range
-50A~50A
Voltage Range
0V-288V
Current Sampling Accuracy
1.0%FSR
Communication interface with PCS
RS485/CAN
Communication interface with BMU
CAN
Communication interface with SBMS
RS485/CAN
Communication with monitoring software/EMS
Ethernet
Support IAP upgrade
Yes
Support HMI display and parameter
Yes(Optional)
Insulation detection
No
High voltage power module
Support DC start (optional)
Dry contact output (normally open)
Up to 3
Maximum qty of BMUs
5
Power
24VDC(18~28V)
Power consumption
≤20W
Size(W*H*D)mm
2U (440*88*500)
Way out
Front
Mid-line
Not support
Tap center
Not support
Net weight
14kg

Packing&Shipping

GCE 90s 288V 50A Master Slave BMS With 15s BMU CAN RS485 LAN Protocol
