Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
Specifications
Brand Name :
Jingtan
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Delivery Time :
60 days
Packaging Details :
wooden case
Description
Products Description
Vacuum Deposition Furnace
It is used for the preparation of carbon-carbon composite materials, and mainly used for the preparation of pyrolytic carbon coating on the surface of graphite, semiconductor devices and heat-resistant scour materials.
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
1) Design temperature: 1250℃/1650℃/1800℃/2200℃
2) Common temperature: 900~1200℃
3) Vacuum degree: < 50Pa
4) Pressure rise rate: 6.67Pa /h(or 150Pa/24h) in cold state of empty furnace
5) Heating mode: graphite resistance heating or induction heating, independent temperature control, good temperature uniformity
6) Atmosphere medium: vacuum /CH4/C3H6/H2/N2/Ar
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
7) Gas control: mass flow meter control, multi-channel gas path, uniform flow field, no deposition dead angle, good deposition effect; multi-stage and efficient exhaust treatment system, easy to clean up;
8) Furnace type: square, round, vertical or horizontal structure (non-standard design), fully enclosed deposition chamber, good sealing effect, strong anti-pollution ability;
9) Furnace cooling mode: furnace shell water cooling, external circulation quick cooling system can be selected, short cooling time, high production efficiency;
Model
JT-0305-C
JT-0505-C
JT-0608-C
JT-0612-C
JT-0812-C
JT-1120-C

JT-1218-C
JT-1520-C
Working Zone Size
φ×H(mm)
300×500
500×500
600×800
600×1200
800×1200
1100×2000
1200×
1800
1500×
2000
Limit Temperature(℃)
2300
Temperature uniformity(℃)
±5
±5
±5/±7.5
±7.5/±10
±7.5/±10
±10/±15
±10/±15
±10/±20
Limit Vacuum Degree(Pa)
1-100
Pressure rise rate(Pa/h)
0.67
Heating method
resistance/induction
Qualification and Patents

Our company philosoph:

We are not your supplier,but your parter and supply the whole thermal treatment furnace solutions with strong R&D research team,stable supply chain with 14+ years experience under the strict ISO9001:2015 quality management system.

Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
The State Intellectual Property Office of the People's Republic of China (SIPO), in accordance with the Patent Law of the People's Republic of China, examined and granted our patent rights:
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating

Patent for carbonization sintering furnace
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating

Patent for bottom discharge graphitization furnace:
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating

Patent for carbon fiber continuous furnace
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating

Patent for high temperature graphitization furnace
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating

Patent for high temperature vacuum hot pressure furnace
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating

Patent for high temperature continuous furifing graphitization furnace
Production process
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
Customer Photoes
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
Logistics System All Around the World.
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
Customer Cooperation Cases
Stainless Steel Vacuum Deposition Furnace Graphite Resistance Heating Or Induction Heating
FAQ

Are you a factory or trading company?

Q: Are you a factory or trading company?
A:Yes,we are China leading high-temperature vacuum furnace manufacturer 14+years,granted with many patent certifications in the domestic market.

Do you have customization or OEM service?

Q: Do you have customization or OEM service??
A:Yes,we have powerful R&D team and high-tech equipment.So we can not only supply the regular model,but also the customizable furnace as the repuirment of our clients.

What's your advantages?

Q:What's your advantages?
A:Quick response to your enquiry
High quality control
Stable supply chain in the domestic maket
Timely delivery
Excellent after-sales service,we can dispatch our engineer to the customer city for installation and debugging.
