45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
Specifications
Price :
USD10,000-80,000/SET
Brand Name :
Jingtan
Certification :
CE
MOQ :
1 set
Delivery Time :
60 days
Packaging Details :
wooden case
Payment Terms :
L/C/T/T
Supply Ability :
5pcs/month
place of origin :
Hunan, China
type :
Induction Furnace
usage :
Sintering Furnace
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
PLC, motor
brand name :
Jingtan
voltage :
380
weight (t) :
5 T
warranty :
1 Year
key selling points :
Accurate temperature control
Temperature control accuracy :
±1℃
Heating material :
graphite tube and graphite rod
Leakage rate :
no more than 10Pa/ hour for 12 hours after pump stop for 15 minutes
Limit temperature :
2450℃
Common temperature :
2300℃
Working Zone Size :
300*300*500mm
Loading Capacity :
45L
Working Atmosphere :
vacuum or inert gas
Warranty of core components :
1 Year
Description
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
One power supply cabinet with two sintering furnaces
It is a kind of intermittent resistance heating furnace and the main application scope is non-pressure silicon carbide sintering, hard alloy, powder metallurgy industry production of various particle sizes of tungsten carbide powder, chromium carbide powder, titanium carbide powder, vanadium carbide powder and other metal powder and composite metal powder, cold pressing molding, sintering treatment. This is the latest structure, one power supply cabinet with two high temperature furnaces.

45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
Model
JT-TSL-45
JT-TSL-128
JT-TSL-375
JT-TSL-720
JT-TSL-1568
JT-TSL-2560
JT-TSL-5000
Common Temperature
300*300*500
400*400*
800
500*500*
1500
600*600*
2000
700*700*
3000
800*800*
4000
1000*1000*5000
Loading Capacity
45L
128L
375L
720L
1568L
2560L
5000L
Limit
Temperature
≤2450℃
Operating temperature
≤2300℃
Limit vaccum
1Pa(In a cold, empty, clean furnace chamber)
Leakage rate
After stopping the pump for 15 minutes, the cold state for 12 hours is not more than 10Pa/ hour
Temperature control accuracy
±1℃
Voltage
380V,50Hz,three Phrase
Heating material
graphite tubes and graphite rods
Gas supply
Argon gas and nitrogen gas can be controlled separately on the valve disc
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder

Characteristic 1:

Intelligent digital display instrument programming PID intelligent digital display temperature controller, new digital display,intelligent control technology, can reduce visual reading and human operation error, greatly improve work efficiency, double row
digital display, key setting,overtemperature alarm.
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder

Characteristic 2:

Microcomputer automatic control, programmable multi-section rising, protecting, cooling curve, automatic heating, heat preservation, cooling and overtemperature protection.
Furnace adopts high temperature durable heat insulation material,which ensure that the temperature outside the furnace body under long-term work does not exceed the allowable value of the national standard.
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder

Characteristic 3:

Internal circulating water system, to ensure the speed of cooling. The furnace body temperature is close to room temperature.
Fast heating, environmental protection and energy saving, high precision, stable performance, good heat preservation effect.
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder
45L-5000L Silicon Carbide Industrial Sintering Furnace High Temperature For Metal Powder

Are you a factory or trading company?

Q: Are you a factory or trading company?
A:Yes,we are China leading high-temperature vacuum furnace manufacturer 14+years,granted with many patent certifications in the domestic market.

Do you have customization or OEM service?

Q: Do you have customization or OEM service??
A:Yes,we have powerful R&D team and high-tech equipment.So we can not only supply the regular model,but also the customizable furnace as the repuirment of our clients.

What's your advantages?

Q:What's your advantages?
A:Quick response to your enquiry
High quality control
Stable supply chain in the domestic maket
Timely delivery
Excellent after-sales service,we can dispatch our engineer to the customer city for installation and debugging.
