Customized Vacuum Hot Press Sintering Furnace for Metal Compounds Ceramics Nanomaterials
Customized Vacuum Hot Press Sintering Furnace for Metal Compounds Ceramics Nanomaterials
Specifications
Price :
USD8,000-60,000/SET
Brand Name :
Jingtan
Certification :
CE
MOQ :
1 set
Delivery Time :
60 days
Packaging Details :
wooden case
Payment Terms :
L/C/T/T
Supply Ability :
5pcs/month
place of origin :
Hunan, China
type :
Induction Furnace
usage :
Sintering Furnace
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
PLC
brand name :
OEM
voltage :
380
weight (t) :
2 T
power (kw) :
100
warranty :
1 Year
key selling points :
Flexible Manufacturing
Maximam temperature :
2800℃
Application :
metal compounds, ceramics, inorganic compounds, nanomaterials
Furnace structure :
double SUS304
Frame type :
double column support structure
Heating elements :
Graphite,molybdenum,tungsten,tantalum
Discharge :
vertical uppeer discharge/side door discharge
Pressure :
one-way/two way pressure
Vacuum degree :
5*10-3Pa
Rated Power :
50-100Kw
Maximum pressure :
20-400 Ton
Condition :
New
Warranty of core components :
1 Year
Showroom Location :
Viet Nam, Philippines
Marketing Type :
Hot Product
Applicable Industries :
scientific research, New material research
Description

China Customized Metal Compounds Ceramics Inorganic Compounds Nanomaterials Vacuum Hot Press Sintering Furnace

Specification

Usage:

The equipment is mainly used for colleges and universities, scientific research units for metal compounds, ceramics, inorganic compounds, nanomaterials, etc., under the condition of vacuum or protective atmosphere for pressure heating and sintering processing, in order to obtain consistent products, such as the production of high-precision silicon nitride ceramic bearings and silicon nitride ceramic substrate.

Model
Work Area Dimension D*H mm
Maximum Temperature℃
Cold limit Vacuum Pa
The pressure ratio Pa/h
Rated Power Kw
Pressure T
Displacement mm
Charge Pressure Mpa
JT-RYL-50
Ф150*200
2400
5*10-3
3
50
20-200
0-100
0.05
JT-RYL-75
Ф200*300
2400
5*10-3
5
75
20-200
0-150
0.05
JT-RYL-100
Ф300*400
2400
5*10-3
6
100
20-200
0-250
0.05
JT-RYL-200
Ф400*500
2400
5*10-3
6
200
20-200
0-300
0.05
JT-RYL-300
Ф500*600
2400
5*10-3
6.5
300
20-200
0-350
0.05
JT-RYL-400
Ф600*700
2400
5*10-3
6.5
400
20-200
0-450
0.05

Features:

(1) Double SUS304 furnace structure, cooling water through the middle, effectively reduce the surface temperature of the furnace body to reduce high temperature damage, reduce the impact on the environment;
(2) frame type double column support structure, using profile welding, overall processing, to ensure the reliability of equipment;
(3) the use of thermal insulation materials and thermal insulation structure, low thermal conductivity, good thermal insulation effect, even at a high temperature can effectively isolate heat, save energy consumption;
(4) Wide temperature range, heating elements of various options, such as graphite, molybdenum, tungsten, tantalum, in the appropriate protective atmosphere, the temperature can reach 2800℃, can adapt to the hot pressing sintering of different materials;
(5) Diversified vacuum system configuration, choose different levels of vacuum according to the process;
(6) Without charging and releasing system, you can choose hot pressing sintering in vacuum environment, also can choose hot pressing sintering in inert atmosphere or reducing atmosphere;
(7) Humanized configuration, both manual operation, can also achieve one-button intelligent operation;
(8) This Furnace can meet multi-purposes, can be used as a simple vacuum or atmosphere sintering furnace;
(9) diversified types, vertical upper discharge, vertical side door discharge, one-way pressure, two-way pressure and so on, arbitrary choice;
(10) This product accepts non-standard customization.
Product parameter:
Customized Vacuum Hot Press Sintering Furnace for Metal Compounds Ceramics Nanomaterials

Title goes here.

1) Double SUS304 furnace structure, cooling water through the middle, effectively reduce the surface temperature of the furnace body to reduce high temperature damage, reduce the impact on the environment;
2) frame type double column support structure, using profile welding, overall processing, to ensure the reliability of equipment;
Customized Vacuum Hot Press Sintering Furnace for Metal Compounds Ceramics Nanomaterials

Title goes here.

3) the use of thermal insulation materials and thermal insulation structure, low thermal conductivity, good thermal insulation effect, even at a high temperature can effectively isolate heat, save energy consumption;
4) Wide temperature range, heating elements of various options, such as graphite, molybdenum, tungsten, tantalum, in the appropriate protective atmosphere, the temperature can reach 2800℃, can adapt to the hot pressing sintering of different materials;
Customized Vacuum Hot Press Sintering Furnace for Metal Compounds Ceramics Nanomaterials

Title goes here.

5) Diversified vacuum system configuration, choose different levels of vacuum according to the process;
6) Without charging and releasing system, you can choose hot pressing sintering in vacuum environment, also can choose hot pressing sintering in inert atmosphere or reducing atmosphere;
7) diversified types, vertical upper discharge, vertical side door discharge, one-way pressure, two-way pressure and so on, arbitrary choice;
