71814 ACD-P4 super-precision bearing, 71814 CD-HCP4 Angular contact ball bearing
71814 ACD-P4 super-precision bearing, 71814 CD-HCP4 Angular contact ball bearing
71814 ACD-P4 super-precision bearing, 71814 CD-HCP4 Angular contact ball bearing
71814 ACD-P4 super-precision bearing, 71814 CD-HCP4 Angular contact ball bearing
Specifications
Brand Name :
SKF
Model Number :
71814
MOQ :
1 pcs
Price :
USD 0.1-100 /PCS
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1000 PCS/MONTH
Delivery Time :
3-7 DAYS
Packaging Details :
SINGLE BOX
Main demensions :
70 mm × 90 mm × 10 mm
Inside diameter :
70 mm
Outside diameter :
90 mm
Thickness/width :
10 mm
Basic dynamic load rating (Cr) :
13.8 kN
Basic static load rating :
16 kN
Reference speed :
14000 r/min
Limiting speed (Oil rpm) :
22000 r/min
Weight, Mass (M) :
0.13 kg
Category :
Angular contact ball bearings, super-precision
Description

71814 ACD-P4 super-precision bearing, 71814 CD-HCP4 Angular contact ball bearing, inner size d is 70mm, Out size D is 90mm, With is 10mm , Dyn.cr(KN): 13.8 Stat.cor(KN): 16 grease rpm(r/min): 14000 oil rpm(r/min): 22000, Weight(KG): 0.13,
71814 ACD-P4 super-precision bearing, 71814 CD-HCP4 Angular contact ball bearing detials as below table , different brands, Parameters are slightly different, only for reference.

Calculation data
Basic dynamic load rating C 13.8 kN
Basic static load rating C0 16 kN
Fatigue load limit Pu 0.67 kN
Attainable speed for grease lubrication 17000 r/min
Attainable speed for oil-air lubrication 26000 r/min
Ball diameter Dw 5.556 mm
Number of balls z 31
Reference grease quantity Gref 1.4 cm³
Preload and stiffness (back-to-back, face-to-face)
Preload class A GA 73 N
Static axial stiffness, preload class A 72 N/µm
Preload class B GB 220 N
Static axial stiffness, preload class B 125 N/µm
Preload class C GC 440 N
Static axial stiffness, preload class C 184 N/µm
Calculation factors
Calculation factor f 1.32
Calculation factor f1 1
Calculation factor f2A 1
Calculation factor f2B 1.1
Calculation factor f2C 1.18
Calculation factor fHC 1.02
Calculation factor f0 17.2
Mass
Mass bearing 0.12 kg

71814 ACD-P4 super-precision bearing, 71814 CD-HCP4 Angular contact ball bearing

71814 ACD-P4 super-precision bearing, 71814 CD-HCP4 Angular contact ball bearing
