DTH API Drill Tube Precision Ground Drill Rod For Water Well Hole Drilling
DTH API Drill Tube Precision Ground Drill Rod For Water Well Hole Drilling
DTH API Drill Tube Precision Ground Drill Rod For Water Well Hole Drilling
DTH API Drill Tube Precision Ground Drill Rod For Water Well Hole Drilling
Specifications
Brand Name :
Jincheng Drilling Tools
Model Number :
All
Certification :
ISO9001,CE
Place of Origin :
China(mainland)
MOQ :
3pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000000pcs/year
Delivery Time :
3-15days
Packaging Details :
Iron shelf
name :
Oil Drill Rod
length :
as required
factory visit :
support
Processing Type :
Forging
package :
iron shelf
MOQ :
3 Pcs
Description

DTH API Drill Tube Precision Ground Drill Rod For Water Well Hole Drilling

Description

Drill pipe is designed to allow the introduction of a drilling fluid or air to the bit and to provide the mechanism to transfer energy developed by the drill motor to the bit. The correct selection of drill pipe, in most instances, determine how successful you are and what options you have as far as depth, bore hole size, and push and pull
down ability.
The selection of drill pipe is one of the most important decisions mainly due to cost and rig

If you need, please contact us freely.

Application

DTH API Drill Tube Precision Ground Drill Rod For Water Well Hole Drilling

DTH API Drill Tube Precision Ground Drill Rod For Water Well Hole Drilling

Technical Parameters of DTH Drill Pipe (Outer Flat Drill Rod):

Diameter Length Wrench Flats Threads
50-194mm 500-10700mm 40,57,65,75,83,95mm F42×10 F48×10 2 3/8''API REG 2 7/8''API REG 3 1/2''API REG 2 3/8''API IF 3 1/2”BECO 4”BECO 4 1/2”BECO 5 1/4”BECO

Outer diameter Thread Wall thickness Length Wrench flat Weight
mm mm mm mm Approx Kg
76 2-3/8 API REG 5.5 1000 57 17
1500 22
2000 26
3000 35
1000 65 17
1500 22
2000 26
3000 35
6.5 3000 46
4500 56
6000 73
89 2-3/8 API REG 5.5 1000 65 20
1500 25
2000 30
3000 40
6.5 1000 21
1500 26
2000 32
3000 45
4500 65
6000 84
102 2-3/8 API REG 6.5 1000 75 25
1500 33
2000 40
3000 55
4500 78
6000 100
2-7/8 API REG 1000 83 25
1500 33
2000 40
3000 55
4500 78
6000 100
114 3-1/2 API REG 6.5 1000 95 31
1500 40
2000 49
3000 66
4500 86
6000

110

Factory

DTH API Drill Tube Precision Ground Drill Rod For Water Well Hole Drilling

Business Information

Minimum Order Quantity: N/A
Price: Negotation
Packaging Details: Standard Export Delivery Package
Delivery Time: 7days
Payment Terms: T/T,Western Union
Supply Ability: Based on Detailed Order

Package and Delivery
DTH API Drill Tube Precision Ground Drill Rod For Water Well Hole Drilling

FAQ
1. Shipping time for an order
We have many stock. As usual, we can delivery the goods as soon as we get the full payment.
2. Quality Control
Strict inspection and testing for every order before shipping out .
3. How can we trust your company?
We support Alibaba trade insurance. Protect products quality, shipment on time and your covered amount.
4. Other Questions?
Welcome contact me directly for more informations.
