50 Hz Perkins Diesel Generator Set 9kVA -2500kVA
50 Hz Perkins Diesel Generator Set 9kVA -2500kVA
Specifications
Place of Origin :
Shanghai, China
Brand Name :
Kinpha or OEM brand
Certification :
CE/CB/ISO9001/ISO14001
Model Number :
JP9-1 ~ JP2250
Output Type :
AC Single Phase
Speed :
1500rmp
Frequency :
50 Hz
Rated Power :
0.8
Rated Voltage :
230V/400V
MOQ :
1 SET
Price :
To be discussed by mail
Packaging Details :
Standard Export packig
Delivery Time :
25-35 days since deposit date
Payment Terms :
T/T , L/C at sight
Supply Ability :
200 set per month
Description
50 Hz Perkins High Quality Diesel Generator Set 9kVA -2500kVA
Jinfa-Perkins series is positioned to its value of:
Leading adaptability in the industrial area
Reliability&Lifetime low cost operation and maintenance
Globally technical & service support
Genset Standard Configuration
Assembled by Perkins diesel engine and world famous brand alternator
Radiator and fan with safety guard
Automatic control panel and electricity output switch cabinet
Float battery charger and solenoids switch as standard supply scope
Strong and durable hi-strength base frame
Perkins Engine
British PERKINS ENGINE COMPANY LIMITED created by entrepreneur Frank•Perkins in British Peterborough in 1932,whichis one of the world’s leading manufacturers of engine.Service Network covers more than 180 countries and areas, all outlets uphold the most stringent standards, to assure that the customers in every corner of the world can obtain the best quality of service. Till now, their 400 series and some of the 1100 series engine made in Wuxi China, all the rest models are all made in India or UK.

Alternator (Stamford, Leroy Somer, MeccAlte, Marathon, etc)

Alternator adopts brushless synchronization alternator of world famous brand, based on a variety of operating voltage requirements, optimizing winding design and eliminating effectively the third harmonic voltage, which together with the superior performance of automatic voltage regulator and PMG(optional), in with superior performance in generating non-linear loads.

Form: single/double bearing

Protection: IP23 (IP44 optional)

Balance: rotator balance is in accordance with ISO1940 and NFC51-112 standard

Over speed: 2250rpm

Insulation Class: H

Mechanical structure: steel base frame

JP SERIES(50Hz), 380-440V, 9-2250kVA
Genset Model Standby Power Prime Power Engine Model Fuel Consumption
100% Loaded		 Dimensions Weight
kVA kW kVA kW mm Kg
JP*9-1 10 8 9 7 403A-11G1 2.4 1346*500*1079 310
JP*13-1 14 11 13 10 403A-15G1 3.6 1439*500*1148 375
JP*15-1 17 15 15 12 403A-15G2 3.9 1439*500*1148 385
JP*20-1 22 18 20 16 404A-22G1 5.0 1611*560*1210 430
JP*30-1 33 26 30 24 1103A-33G 6.6 1837*700*1350 800
JP*45-1 50 40 45 36 1103A-33TG1 10.0 1970*700*1350 890
JP*60-1 66 53 60 48 1103A-33TG2 13.9 2050*700*1350 910
JP*65-1 72 57 65 52 1104A-44TG1 14.8 2200*700*1350 1050
JP*80-1 88 70 80 64 1104A-44TG2 18.7 2200*700*1350 1050
JP*100-1 110 88 100 80 1104C-44TAG2 22.6 2264*700*1380 1115
JP*135-1 149 119 135 108 1106A-70TG1 31.5 2690*800*1350 1375
JP*150-1 165 132 150 120 1106A-70TAG2 35 2690*800*1350 1375
JP*180-1 199 160 180 144 1106A-70TAG3 40.2 2850*850*1350 1400
JP*200-1 220 176 200 160 1106A-70TAG4 42.9 2850*850*1350 1400
JP*230-1 253 202 230 184 1506A-E88TAG2 47.2 2860*1062*1830 1952
JP*250-1 275 220 250 200 1506A-E88TAG3 49.1 2860*1050*1830 1980
JP*275-1 303 242 275 220 1506A-E88TAG4 56 2950*1050*1850 2300
JP*300-1 330 264 300 240 1506A-E88TAG5 61 2950*1050*1850 2300
JP*350-1 385 308 350 280 2206C-E13TAG2 74.3 3460*1168*2029 2980
JP*400-1 440 352 400 320 2206C-E13TAG3 85.3 3460*1168*2029 3000
JP*455-1 501 400 455 364 2206C-E15TAG1 95 3780*1268*2003 3760
JP*500-1 550 440 500 400 2506C-E15TAG2 104 3780*1268*2003 3760
JP*600-1 660 600 600 480 2806C-E18TAG1A 127.3 3780*1536*2180 4370
JP*650-1 715 572 650 520 2806C-E18TAG2 132 3780*1536*2180 4725
JP*750-1 825 660 750 600 4006-23TAG2A 149 4200*1710*2340 5560
JP*800-1 880 704 800 640 4006-23TAG3A 163 4200*1710*2340 5600
JP*900-1 990 792 900 720 4008TAG1A 195 4657*2064*2410 7300
JP*1000-1 1100 880 1000 800 4008TAG2A 215 4675*2064*2410 7320
JP*1125-1 1237 990 1125 900 4008-30TAG3 235 4700*2080*2435 9000
JP*1250-1 1375 1100 1250 1000 4012-46TWG2A 259 4700*2080*2435 9000
JP*1350-1 1485 1188 1350 1080 4012-46TWG3A 278 4750*2080*2435 9100
JP*1500-1 1650 1320 1500 1200 4012-46TAG2A 305 4750*2080*2435 9100
JP*1710-1 1881 1505 1710 1368 4012-46TAG3A 356 4900*2080*2435 9200
JP*1850-1 2035 1628 1850 1480 4016-61TRG1 383 5800*2800*3360 10200
JP*2000-1 2200 1760 2000 1600 4016-61TRG2 421 6000*2870*3295 10800
JP*2250-1 2475 1980 2250 1800 4016-61TRG3 473 6100*2870*3295 11000

50 Hz Perkins High Quality Diesel Generator Set 9kVA -2500kVA
