Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes
Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes
Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes
Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes
Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes
Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes
Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes
Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes
Specifications
Brand Name :
Hommar
Model Number :
HM-35T-CT
Certification :
CE,RoHS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
200 pcs per month
Delivery Time :
35-45 working days
Packaging Details :
No-solid wooden box
Power :
8KW
Production Speed :
3000-7000 pcs/hr
Foil Printing :
Yes
Technical Training :
Available
L/C :
Available
Warranty :
rotary injection molding machine
Description

35T Foiled Hang Tag Automatic Injection Moulding Machine Standard 10 Cavities For Clothes

Applications:

PP cloth tag for clothes

PS String tags for hand bag

Seal tags for student bag

Label tags

Foiled Printing string tags

General cotton Tags

Waxed Tag string

Features:

Full Automatical,no need labor

High efficiency,cycle time 6-10s, 10-16 cavities

High speed injection machine, saving power by 60%

One stop purchase ,a whole set Solution

On site technicial support available

Siemens PLC with internet, technicial support online

Easy Changed Mold and LOGO

Parameters:

Injection Unit
Screw Diameter mm 26-32
Screw Stroke mm 140
Shot Volume cm3 64-96
Injection Weight g/oz 49-80/1.7-2.8
Plasticizing Capacity g/s 4.2-8.2
Max. Injection Pressure kgf/cm2 2530-1563
Injection Rate cm3/s 44-71
Injection Speed mm/s 116
Screw Speed r.p.m. 0-240
Nozzle Force tf 4.8
Nozzle Ejection Stroke mm 45 or more
Clamping Unit
Clamping Force tf 35
Opening Force tf

7.8
Clamping Stroke mm 200
Min. Mold Height mm 150
Max. Distance mm 350
Distance between Columns mm 370*210
Max. Mold Size mm 350*350
Platens Size mm 500*360
Ejector Stroke mm 40
Ejector Force tf 1.75
Qty of ejector pcs 1
System Pressure kgf/cm2 140
General
Oil Tank Cpacity L 130
Motor Power KW 5.5
Heater Power KW 3.6
Temperature Stage 2+1
Working Table Height mm 929
Dimensions
Machine Size mm 1539*1152*2269
Weight T 1.3
Packing Size mm 1700*1300*1800
Packing Weight T 1.5

Key parts List

Item Item Name Brand Original of Country
1 PLC DIHZHOU TAIWAN
2 Screw and barrel HUAYE CHINA
3 Electric motor Universal CHINA
4 Seal kit HALLITE United Kingdom
5 Solenoid valves Yuken Taiwan
6 Proporional valves Yuken Taiwan
7 Hydraulic motor White United States
8 Linear Scale Gefran Italy
9 Gear pump Eckerle Germany
10 Electrical Connectors Schneider France
11 Tie bar Genaral Taiwan
12 Heater bands Schneider France

Accessory List

1 Injection Machine x 1
2 Robot x 1
3 Mold x 1


Optional Accessories(Charged)
1 Water Chiller x 1
2 Grinder x 1
3 Blender x 1
4 Dryer x 1
5 Loading machine x 1
6 Honeycomb Dehumidifiers x 1
7 Mold Temperature Controller x 1

Price List

QTY=1 set 19000-79000 USD/set FOB Shenzhen
QTY=2-5 set 2-3% off USD/set FOB Shenzhen
QTY=6-10 set 5-7% off USD/set FOB Shenzhen
More Negotiable

After-sales service

QTY=1 PCS,online technical support

QTY=2-4 PCS,our techincians on site but tickets, hotel and food are borne by you and labor fee 100 USD/day/person

QTY=5-6 PCS,techincians on site ,labor free but hotel and food are borne by you.

More Details

Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes

Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes

Corner of Workshop

Foiled Hang Tag Automatic Injection Moulding Machine 10 Cavities For Clothes
