HM-85SD-SO BMC Injection Molding Machine With Energy Saving Motor CE Approved
HM-85SD-SO BMC Injection Molding Machine With Energy Saving Motor CE Approved
HM-85SD-SO BMC Injection Molding Machine With Energy Saving Motor CE Approved
HM-85SD-SO BMC Injection Molding Machine With Energy Saving Motor CE Approved
HM-85SD-SO BMC Injection Molding Machine With Energy Saving Motor CE Approved
HM-85SD-SO BMC Injection Molding Machine With Energy Saving Motor CE Approved
Specifications
Brand Name :
Hommar
Model Number :
HM-85SD-SO
Certification :
CE , RoHS
Place of Origin :
China
MOQ :
1
Price :
USD 49000-79000/pcs
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
200 pcs per month
Delivery Time :
35-45 working days
Packaging Details :
No-solid wooden box
Machine :
Medical Device Pump Solenoid Coil Thermosetting Molding Machine
Power Comsuption :
7.5KW
Oil Tank :
230L
Cavities :
2-4pcs per mold
QTY of Mold :
2 sets
Special :
2 Sliding tables
Description

BMC Medical Device Pump Solenoid Coil Thermosetting Molding Machine with Energy Saving Motor

Vertical-type four-column mould clamping. Vertical-type injection, Chinese/English electrical control, screen display, effective, fast and stable hydraulic system, reasonable mechanical structures, convenient operation, suitable for the production of second compacting products such as electric and electronic products.

Advantages / Differences

This machine is equipped with world up-class components.It performs stable and lasting.

No troubles or break or broken in 5-10 years.

Customer Choosing Reasons

1 . This machine is the most economic and high efficiency.

2 . Its cost and performance rate is very high.

3 . It is cheaper by 30% than the machine with rotary table

4 . Its output is twice than the fixed type machine

5 . It is CE certificated

What can Medical Device Pump Solenoid Coil Thermosetting Molding Machine do?

BMC Spring Solenoid Valves Coil

BMC Solar Solenoid Coil

BMC Veichle Solenoid Valves

BMC Firefight Pump Solenoid Coil

BMC Gas Solenoid Coil

BMC Medcial Device Solenoid Coil

Technicial Parameters:

Injection Unit Screw Diameter mm 30-36
Screw Stroke mm 140
Shot Volume cm3 99-142
Injection Weight g/oz 91/3.2-131/4.6
Plasticizing Capacity g/s 8.2-16.5
Max. Injection Pressure kgf/cm2 1890-1312
Injection Rate cm3/s 72-104
Injection Speed mm/s 103
Screw Speed r.p.m. 0-230
Nozzle Force tf 4.8
Nozzle Ejection Stroke mm 45 or more
Clamping Unit Clamping Force tf 85
Opening Force tf

8.4
Clamping Stroke mm 250
Min. Mold Height mm 230/310
Max. Distance mm 480/560
Distance between Columns mm 500*340
Max. Mold Size mm

450*400
Platens Size mm 1100*490
Ejector Stroke mm 100
Ejector Force tf 1.75
Qty of ejector pcs 3
System Pressure kgf/cm2 140
Other Oil Tank Cpacity L 280
Motor Power KW 11
Heater Power KW 6.4
Temperature Stage 3+1
Working Table Height mm 980
Dimensions Machine Size mm 2710*1100*3335
Weight T 3.6
Packing Size mm 2900*1200*2000+700*600*1750
Packing Weight T 3.8

Key Components List

Item Item Name Brand Original of Country
1 PLC DIHZHOU TAIWAN
2 Screw and barrel HUAYE CHINA
3 Electric motor Universal CHINA
4 Seal kit HALLITE United Kingdom
5 Solenoid valves Yuken Taiwan
6 Proporional valves Yuken Taiwan
7 Hydraulic motor White United States
8 Linear Scale Gefran Italy
9 Gear pump Eckerle Germany
10 Electrical Connectors Schneider France
11 Tie bar Genaral Taiwan
12 Heater bands Schneider France

Accessory List

1 Injection Machine x 1
2 Mold x 1


Optional Accessories(Charged)
1 Water Chiller x 1
2 Grinder x 1
3 Blender x 1
4 Dryer x 1
5 Loading machine x 1
6 Honeycomb Dehumidifiers x 1
7 Mold Temperature Controller x 1

Price List

QTY=1 set 21500-25000 USD/set FOB Shenzhen
QTY=2-5 set 2-3% off USD/set FOB Shenzhen
QTY=6-10 set 5-7% off USD/set FOB Shenzhen
More Negotiable

After-sales service

QTY=1 PCS, online technical support

QTY=2-4 PCS, our techincians on site but tickets, hotel and food are borne by you and labor fee 100 USD/day/person

QTY=5-6 PCS, techincians on site , labor free but hotel and food are borne by you.

View video on Youtube

More Details of Medical Device Pump Solenoid Coil Thermosetting Molding Machine

Samples made by Medical Device Pump Solenoid Coil Thermosetting Molding Machine
