High speed Nonwoven Carding Machine for geotextile fabric production line
High speed Nonwoven Carding Machine for geotextile fabric production line
High speed Nonwoven Carding Machine for geotextile fabric production line
High speed Nonwoven Carding Machine for geotextile fabric production line
High speed Nonwoven Carding Machine for geotextile fabric production line
High speed Nonwoven Carding Machine for geotextile fabric production line
Specifications
Brand Name :
HongYi
Model Number :
450PJM
Certification :
CE /ISO9001
Place of Origin :
CHINA
MOQ :
1 SET
Price :
negotiation
Payment Terms :
T/T, L/C, Western Union, Western Union, MoneyGram
Supply Ability :
1 LINE 30 DAYS
Delivery Time :
7DAYS AFTER RECEIVING THE PAYMENT
Packaging Details :
NUDE OR WOODEN CASE
productivity: :
100-600M/MIN
production rate: :
600m/min
Machine Type :
Double cylinder double doffer
Width :
1550-3200mm
Speed :
Max. 70m/min
Advantage :
High Production Capacity
Description

High speed Nonwoven Carding Machine for geotextile fabric production line

Effective Width(mm) 2500/3500
Max. Output(kg/h) 750
Max. Speed (m/min) 100
Structure Double cylinder,Double doffer,Double agglomeration
Sub-Cyclinder Dia. of Sub- Cylinder (mm) 1050
No. of working roller (groups) 3
Main cylinder Dia. of Sub- Cylinder (mm) 1500
No. of working roller (groups) 5

High speed Nonwoven Carding Machine for geotextile fabric production line

Structure

1. Horizontal feeding lattice is PVC lattice, with pressing roller for evenly feeding;
2. Four rollers for feeding with diameter 90mm, anti-metal protection device is used at the input part of the machine, which could test the metal and has auto-stop warning;
3. There are five suits of working roller and stripping roller on main cylinder and four suits of working roller and stripping roller on breast cylinder to card fiber completely and form web evenly;
4. Edge-suction system is equipped and the dust particles will be transferred to special dust cage;
5. Walking platforms are placed on two sides of machine for maintenance.
6. Machine safe guard cover is transparent organic glass.

item
value
Marketing Type
New Product 2020
Automatic Grade
Full-automatic
Voltage
380/440V
Power
40kw
Certification
CE/ ISO9001
Working width
1550mm, 1850mm, 2000mm, 2300mm, 2500mm, 3200mm
Production Capacity
800kg/h
Diameter of cylinder
1230mm, 850mm
Suitable fiber
1.5D-15D*38mm-64mm
Output speed
Maximum 70m/min
  • Product: soft wadding
  • Product net width : up to 4500mm(or wider dependent on individual requirement )
  • Product weight:60-1500g/m2
  • Product thickness :3-200mm

High speed Nonwoven Carding Machine for geotextile fabric production lineHigh speed Nonwoven Carding Machine for geotextile fabric production line

Pre-Sales Service
* Inquiry and consulting support
* Sample testing support
* View our factory


After-Sales Service
* Training how to install the machine , training how to use the machine
* Engineers available to service machinery overseas
* Warranty :12 months
* Certificate : ISO9001 CE


Trade information
* Payment terms: 30%deposite by TT, LC , Western Union ,Moneygram 70% as balance paid before delivery LC
* Delivery time: Approx 7 working days after receiving the rest payment
* Package: make, wooden case
* Warrantty:12 months
* After-sales service: we will send 2-3 workers to do the installation and commissioning of the line at the request of the buyer . and the buyer should provide round-trip airplane tickets , accommodation, and allowance, the allowance is 70USD /person/day
* HS code:84490090
* MOQ: 1set
