Aluminum Automatic Swing Entry Gate , House Front Door Security System
Aluminum Automatic Swing Entry Gate , House Front Door Security System
Specifications
Brand Name :
Hongmen
Model Number :
HDR51B
Certification :
CE
Place of Origin :
China
MOQ :
L=3m * H=1.5m
Supply Ability :
30.00m/month
Delivery Time :
10 Working Days
Packaging Details :
Iron rack plus plywood
Material :
Industrial Grade Aluminium Alloy
Colour :
Customized
Surface Treatment :
Powder Coated
IP Rating :
44
Operating :
Wireless Remote Control
Motor :
220VAC / 250W
Description

Aluminum Automatic Swing Entry Gate , House Front Door Security System

Features:

  1. Colour Available: Customized
  2. Suitable For:
    • Private Residential Area
    • Bungalow Entrance
    • Villa Gate
  3. CE certified.
  4. EMO button (Emergency stop button).
  5. Trackless operation.
  6. Smart power outage clutch.
  7. Wireless remote control (433MHz).
  8. Powder coating
  9. Dispatch in modules form (Transportation friendly).
  10. Industrial grade aluminum alloy (6063-T5).
  11. Anti- collision IR sensor.
  12. Anti- climb photo cell.

Specifications:

Material Specification:

Description Material Hardness (HW) Specification (mm)
Front Gate Frame Q235 / 200*200*d5.0
Rear Gate Frame Q235 / 200*200*d3.0
Auxiliary Gate Frame 6003-T5 10-13 2.5*25*d1.5
Slide Bar 6003-T5 10-13 120*74*d2.5
Upright Post 6003-T5 10-13 120*85*d2.5

Technical Specification:

Operation Voltage 220V± 10%, 50Hz-60Hz
Operation Temperature -25ºC to +70ºC
Environment Humidity < 90%
Operation Speed 16m/min
Motor Power Rating 250W
Motor RPM 1400r/min
IP Rating IP44
Insulation Grade F
Speed Reduction Ratio 1000: 1
Remote Distance 50m (empty space)

Warranty:


1. Drive Motor is warranted against manufacturer’s defect for lifetime
2. Standard warranty for all components is valid for 12 months from the date of delivery
3. This warranty does not include damages caused by:
a. Wear and Tear
b. Theft
c. Accidents
d. Act of God & Natural Disaster
e. Unstable power supply (i.e. inconsistent voltage or lightning)

Disclaimer:

Hongmen Trading Co., Limited does not have any control of the final use of the goods supplied. We do not warrant the goods to be suitable for any other particular purpose. So far as statute permits and other express or implied term, condition or warranty, whether arising under statute or otherwise, as to fitness, suitability, quality condition, correspondence with description or sample or merchantability of the goods is hereby excluded from the contracted terms.

Pictures:
