SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
Specifications
Place of Origin :
Shandong, China
Brand Name :
Hongqiao
Certification :
MTC
Packaging Details :
Standard seaworthy export packing: 3 layers of packing, inside is kraft paper, water plastic film is in the middle and outside GI steel sheet to be covered by steel strips with lock.
Supply Ability :
5000 Ton/Tons per Month
Price :
$700.00 - $900.00/Tons
Standard :
AiSi, ASTM, bs, DIN, GB, JIS
Steel Grade :
SPCC/DX51D
Technique :
Hot Rolled
Surface Treatment :
galvanized
Width :
as your requirement
Length :
as your requirement
Tolerance :
±1%
Processing Service :
Bending, Welding, Decoiling, Cutting, Punching
Grade :
spcc
Product Name :
spcc
Surface :
cold rolled/hot rolled
Material :
ASTM/AISI/SGCC/CGCC/TDC51DZM/TDC52DTS350GD/TS550GD/DX51D+Z Q195-q345
Shape :
Plate. Coil
Thickness :
0.08-6.0mm
Process :
Cutting
Type :
Type:Steel Coil
Name :
Cold Rolled Mild Steel Strip
Zinc Coating :
40-275G/M2
Port :
shanghai/qingdao/tianjin
Description

DC01 03 05 06 SPCC Spce Spcd Dx51d+Z150 Cold Rolled Steel Plate Sheet Galvanized Steel Coils

We can make strips as thin as 0.30mm (10μm),with a guaranteed precision thickness of ±1~3μm. Many grades for carbon steel coil stock products are available , for example,Q235,ASTM A283, SS400,S235JR,Q345,ASTM A572,S355,A36 and so on .We also can customize the thickness, width,surface finishing,hardness, and other specifications according to your needs. Please feel free to contact us.Cold Rolled Steel Plate/ Sheet cold rolled carbon steel coil

Item name

Galvanized steel coil / strip

Grade

DX51D+Z

S250GD+Z

SGCC

DX52D+Z

S280GD+Z

SGCD

DX53D+Z

S350GD+Z

SGCE

DX54D+Z

S550GD+Z

DX56D+Z

Thickness

0.12 ~ 3.00 mm (cold rolled)

1.20 ~ 4.60 mm (Hot-rolled )

Width

10 - 600 mm (strip)

600 - 1250 mm (coil)

Tolerance

Thickness: ±0.01 mm

Width: ±2 mm

Coil ID

508 mm - 610 mm

Coil weight

3 - 8 ton or as client requirement.

Zinc coating

30g - 275g / m2

Spangle

Big spangle,Regular spangle,Mini spangle,Zero spangle

Surface treatment

Oil,Passivation, Chromated, Skin-passed, Anti-finger Print

HS code

code 72104900

Application

Widely used in road, railway, civil construction, water conservancy construction; all kinds of machinery, electrical appliances, window protection and aquaculture, etc.

Package

Standard export package (Plastic film in the first layer,second layer is Kraft paper. Third layer is galvanized sheet)

Delivery time

Within 15 workdays after deposit received

Remarks

Insurance per to Contract terms;
MTC will be handed on with shipping documents;
We accept the third party certificatation test.

STEEL GRADE

CHEMICAL COMPOSITION %

MECHANIC PROPERTY

C.B OF

COATING

C

Si

Mn

S

P

T.S

Y.S

E.L

COATING

x103

x103

x102

x103

x103

Mpa

Mpa

%

d=0 180°

G/M²

JIS G3302 SGCC

12

30

41

31

21

480

300

13

OK

Z60-150

JIS G3302 SGCH

12

10

21

18

8

680

650

20

OK

Z60-150

ASTM A653 CS.B

29

30

60

35

30

386

250-380

20

OK

Z60-275

DX51D+Z

20

21

18

1.8

11

355

245

38

OK

Z60-275

G550

12

6

73

5

17

715

654

8

OK

Z60-275
SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06

SPCE SPCD Dx51d Z150 Galvanized Carbon Steel Strip DC03 DC05 DC06
