12 SVGA Kiosk Touch Screen Monitor Open Frame Lcd Display 350cd/m2
12 SVGA Kiosk Touch Screen Monitor Open Frame Lcd Display 350cd/m2
12 SVGA Kiosk Touch Screen Monitor Open Frame Lcd Display 350cd/m2
12 SVGA Kiosk Touch Screen Monitor Open Frame Lcd Display 350cd/m2
12 SVGA Kiosk Touch Screen Monitor Open Frame Lcd Display 350cd/m2
12 SVGA Kiosk Touch Screen Monitor Open Frame Lcd Display 350cd/m2
12 SVGA Kiosk Touch Screen Monitor Open Frame Lcd Display 350cd/m2
12 SVGA Kiosk Touch Screen Monitor Open Frame Lcd Display 350cd/m2
Specifications
Brand Name :
OEM or CNHOPESTAR
Model Number :
HOP121PC-8
Certification :
CE&FCC&Rohs
Place of Origin :
Guangdong,China
MOQ :
1
Price :
Price can be negotiable
Payment Terms :
T/T, L/C
Supply Ability :
50000 pcs/month
Delivery Time :
5~7 days
Packaging Details :
59x10x27cm
Screen size :
12 inch
Color :
Black
Resolution :
1024x768
Interface type :
VGA and DVI , HDMI - optional
Type :
Capacitive 10 points touch
Brightness :
350cd/m2 (1000cd/m2, optional)
Installation :
Kiosk, embeded, wall mount
Warranty :
3 years
Description

12" SVGA Kiosk Open Frame Monitor High Brightness Capacitive Touch Display

  • 12.1" 1024 x 768 XGA, 800 x 600 SVGA panel with LED backlight for 20% power saving and environmental protection
  • -20°C~+60°C wide operating temperature support
  • 10 points capacitive touchscreen solution
  • Combo touch interface of RS-232 and USB
  • Dual signal interface with VGA and DVI

General
Series Water-proof and Open frame
LCD Type 12.1” TFT-LCD
Video Input VGA and DVI , HDMI - optional
OSD controls Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Power Supply Type: External brick
Input (line) voltage: 100-240 VAC, 50-60 Hz
Output voltage/current: 12 volts at 4 amps max
Mount Interface 1)VESA 75mm and 100mm
2)2)Mount bracket, horizontal or vertical

LCD Specification
Active Area(mm) 246.0(H)×184.5(V)
Resolution 1024*768
Dot Pitch(mm) 0.3075×0.3075
Nominal Input Voltage VDD +3.3V(Typ)
Viewing angle (v/h) 60°/70°(CR>5)
Contrast 1000:1
Luminance(cd/m2) 350, 1000cd/m2 - optional
Response Time(Rising/Falling) 5ms/5ms
Support Color 16.2M colors
Backlight MTBF(hr) 50000

Touchscreen Specification
Type Capacitive touch screen
Resolution 10points touch
Light Transmission 92%
Touch Life Cycle 50 millions
Touch Response time 2ms
Touch System Interface USB interface
Power consumption +5V@80mA
