Stainless Steel Industrial Gas Fired Steam Boilers Dual Fuel Oil Gas Low Noise

6 tons(4.2MW) of fuel oil gas steam boiler technical parameters:

Brand: Yongxing

Model: WNS6-1.25-Q(Y)

Rated evaporation t/h: 6

Rated steam pressure Mpa: 1.25

Feed water temperature °C: 105

Rated steam temperature °C: 194

Heating area m2: 141.7

Water volume m3;:9

Dimensions mm: 5300*2380*2644

Boiler weight kgs: 12675

After-sales service: boiler mainframe life-long maintenance

Whether to provide auxiliary equipment: if necessary, can provide auxiliary equipment

Applicable fuel: light oil, heavy oil, natural gas, city gas, gas and coke oven gas, etc.

Technical parameters of 6 tons(4.2MW) of fuel gas hot water boiler:

Brand: YONGXING

Model: WNS4.2-1.0/95/70-Q(Y)

Rated thermal power MW: 4.2

Rated water pressure MPa: 1.0

Rated water temperature °C: 95

Feed water temperature °C: 70

Heating area m2: 141.7

Water volume m3:9

Dimensions mm: 5300*2380*2644

Boiler weight kgs: 12675

After-sales service: boiler mainframe life-long maintenance

Whether to provide auxiliary equipment: if necessary, can provide auxiliary equipment

Applicable fuel: light oil, heavy oil, natural gas, city gas, gas and coke oven gas, etc.

oil fired steam boiler Special Advantages

1. Protective device

Timing operation, the control system can automatically enter the work or off-duty state by operating the timing function. The control system can set multiple sets of timing periods within 24 hours. The system enters the office state during any of the time periods in which the current time is in multiple sets of timing periods.

During the regular working hours, the screen is displayed in an automatic state. Out of work outside the working time period. Each set of time periods includes an open time (hour, minute) and a close time (hour, minute). The set operation can set or modify the time, minute and current time of the three control time segments. Users can set different temperature ranges for different time periods.

2. Broken record

When a fault occurs, the alarm message is displayed in real time, and the cause of the fault and the time of the fault are recorded. The controller is capable of permanently recording nearly five occurrences of faults for future reference.

3. Password protection

You can manually set a password for the controller to prevent others from setting the running parameters at will, causing the operation to be abnormal. The user can choose password protection (password protection is valid) or password protection (password protection is invalid).

4. Part of the model is completely factory

The pre-installation of the main accessories will reduce your troubles at the installation site.

5. Control System

An intelligent digital product that requires a finger to operate the entire operation.

6. Perfect protection

The boiler overpressure interlocking protection device, the controller alarms, the burner stops moving, the automatic sewage is opened, and the safety valve is opened.

7. Easy to maintain

The boiler is equipped with a hand (head) hole, which can be easily cleaned and repaired if necessary.

Boiler applicable industries: hot spring bath, sauna steam room, printing and dyeing textile, factory office school, medical and pharmaceutical, hotel catering, food processing, chemical plant, socks factory heat setting, garment processing, industrial steam washing, farm heating and drying, etc.
