Industrial High Efficiency Gas Fired Steam Boiler 1/2//4/6/8/10 For Pharmaceutical Industry
Industrial High Efficiency Gas Fired Steam Boiler 1/2//4/6/8/10 For Pharmaceutical Industry
Industrial High Efficiency Gas Fired Steam Boiler 1/2//4/6/8/10 For Pharmaceutical Industry
Industrial High Efficiency Gas Fired Steam Boiler 1/2//4/6/8/10 For Pharmaceutical Industry
Industrial High Efficiency Gas Fired Steam Boiler 1/2//4/6/8/10 For Pharmaceutical Industry
Industrial High Efficiency Gas Fired Steam Boiler 1/2//4/6/8/10 For Pharmaceutical Industry
Specifications
Brand Name :
Yongxing
Model Number :
WNS
Certification :
CE/ISO
Place of Origin :
Henan China
MOQ :
1set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
1-1000 set
Delivery Time :
25 works day
Packaging Details :
Nude Package,Package with Steel Box,Wooden Box
Fuel :
Oil-fired,Gas-fired,natural gas,lpg,lng
Output :
Steam
Type :
Natural Circulation
Thermal efficiency :
92%
Color :
Customer's Requirement
Design fuel :
Light Oil,etc,Heavy Oil,Oil/Gas,Gas
Pressure :
Low Pressure(1.25MPa)
After-sales service provided :
Engineers available to service machinery overseas
Class :
A
Control System :
Automatic
Usage :
Industrial
Style :
Horizontal
Description

Best price industrial natural gas fired boiler 1/2//4/6/8/10 with high efficiency for pharmaceutical industry

The fuel used in the natural gas fired boiler is burned into the furnace by the burner, and no ash is generated after combustion.

Compared with the coal-fired boiler, the gas boiler does not need to be broken, transport coal-fired facilities, economizer, and The dust removal device has the characteristics of compact structure, small volume, light weight, small floor space, small pollution and high degree of automation, and is increasingly favored by users.


Natural gas fired boiler structural features:
1. The combustion chamber of WNS boiler adopts corrugated furnace, which effectively increases the heat exchange area, enhances the turbulent heat transfer of high temperature flue gas, and reduces the influence of thermal expansion and contraction on the quality of equipment.


2. The natural gas fired boiler adopts a three-return structure, and the tobacco pipe is symmetrically arranged on the left and right sides. This structure ensures the best state of heat exchange area and heat transfer efficiency.


3. The natural gas fired boiler adopts a fully automatic control system to properly regulate the combustion of the fuel.


4. The natural gas fired boiler has water level monitoring, ignition, flameout, steam overpressure automatic alarm and protection function to ensure safe operation of boiler combustion.


5. The natural gas fired boiler is equipped with international advanced imported burners, which have high combustion efficiency (more than 86%)


6. The concentration of harmful substances in soot is very low, which can effectively reduce the pollution to the environment.


7. The condensing heat ex-changer is added to the tail of the boiler to reduce the exhaust gas temperature and absorb the waste heat in the flue gas to improve the efficiency of the boiler (up to 95%).


8. The natural gas fired boiler is designed with a fire hole and an inspection passage. The combustion flame can be easily observed during the operation of the equipment, and the furnace is easy to repair and maintain.

Industrial High Efficiency Gas Fired Steam Boiler 1/2//4/6/8/10 For Pharmaceutical Industry

Natural gas fired boiler data sheet

Model

Rated evaporation capacity(t/h)

Working Pressure(Mpa)

Steam Temperature(℃)

Feed Temperature(℃)

Transportation Size(m)(L×W×H)

WNS1-0.7-Y(Q)

1

0.7

170

20

3.3×1.8×2.1

WNS1-1.0-Y(Q)

1

1

184

20

3.3×1.8×2.1

WNS2-1.0-Y(Q)

2

1

184

20

4.4×2.1×2.5

WNS2-1.25-Y(Q)

2

1.25

194

20

4.4×2.1×2.5

WNS4-1.25-Y(Q)

4

1.25

194

20

4.7×2.5×2.9

WNS4-1.6-Y(Q)

4

1.6

204

20

4.7×2.5×2.9

WNS6-1.25-Y(Q)

6

1.25

194

20

5.9×2.6×3.0

WNS6-1.6-Y(Q)

6

1.6

204

20

5.9×2.6×3.0

WNS8-1.25-Y(Q)

8

1.25

194

105

5.9×2.8×3.1

WNS8-1.6-Y(Q)

8

1.6

204

105

5.9×2.8×3.1

WNS10-1.25-Y(Q)

10

1.25

194

105

7.7×2.8×3.1

WNS10-1.6-Y(Q)

10

1.6

204

105

7.7×2.8×3.1

WNS15-1.25-Y(Q)

15

1.25

194

105

7.0×3.1×3.6

WNS15-1.6-Y(Q)

15

1.6

204

105

7.0×3.1×3.6

WNS20-1.25-Y(Q)

20

1.25

194

105

8.3×3.4×4.0

WNS20-1.6-Y(Q)

20

1.6

204

105

8.3×3.4×4.0

Product reference
1 Pakistan WNS1-1.0-Y (Q) Application: Chemical plant
2 Indonesia WNS2-1.0-Y (Q) Application: Building industry
3 Thailand WNS1-1.0-Y (Q) Application: Laundry room
4 Malaysia WNS8-1.25-Y (Q) Application: Chemical industry
5 Indonesia WNS6-1.25-Y (Q) Application: Textile industry
Packing list
1 Boiler main part 1set
2 Imported gas/oil burner 1set
3 Electric control box 1set
4 Valve & Gauge used on boiler main part 1set
5 Feeding water Pump 2set
6 Smoke chimney 1set
7 Water treatment equipment 1set
8 Steam distributor 1set
