Large Amount Feeding Portable Automatic Scrap Car Baler Removable Style
Large Amount Feeding Portable Automatic Scrap Car Baler Removable Style
Large Amount Feeding Portable Automatic Scrap Car Baler Removable Style
Large Amount Feeding Portable Automatic Scrap Car Baler Removable Style
Specifications
Model Number :
CB-5000 ,CB-6000
Place of Origin :
Jiangsu P.R. China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
5 sets /month
Delivery Time :
As your requirement
Packaging Details :
Seaworthy packing
Brand Name :
DLK
Condition :
New
Automatic Grade :
Automatic
Color :
Customized
Working Pressure :
31.5Mpa
Driven Type :
Hydraulic
Bale Density(Kg/m^3) :
≥2000(Fe)
Quality :
Grade A
Description

Hydraulic Drive Portable Baler Removable Style 500 - 600Tons Nominal Force

Applications:


Mobile working, diesel engine driven, no power needed, which are used for scrap; Scrap cars; other metal structures and non-ferrous metals(stainless steel, aluminum alloy, steel,etc).of compression baling.

Feature:

1. The work bin of machine can contain big volume and a big area of scrap materials at one time.It is especially convenient for large scraps to bale in a short time.

2. Mechanical and electrical integration of liquid control, easy to learn and operate.

3. Hydraulic drive, operation stable and high efficiency.

4. PLC control, high reliability, simple maintenance.

5. Removable style, one equipment can be used more than one yard to reduce the cost of equipment.

1

Press box size (L*W*H)

5000*2000*1200mm

2

Bale size (W*H)

800*700mm

3

Hydraulic system working pressure

25MPa

4

Total power

260HP

Cummins

5

Overall dimension

11000*3000*4000 (side wings open)

L*W*H

11000*2300*4000mm (side wings close)

L*W*H

7

Cover area

15000*4000mm

L*W

8

Operating system

Manual

Jiangyin Dehong

9

Cooler

Oil-steam heat exchange

Jinrong Cooler

No.

CB-4000 Technical specification

Remark

1

Main cylinder

Model

YG220/160—1660

2set

Nominal pressure

2000KN*2

Trip

1660MM

2

First class cylinder

Model

YG200/140-550

2set

Nominal pressure

800KN*2

Trip

550MM

3

Second class cylinder

Model

YG200/140-550

2set

Nominal pressure

800KN*2

Trip

550MM

4

Press box size(L×W×H)(MM)

4000*2100*1300

6

Bale size(L×W×H)(MM)

(700)*650*650

7

Working pressure(Mpa)

21.5 (turn out system6Mpa)

8

Bale density(Kg/m3)

≥2000(Fe)

9

Discharge bale out

Grab machinery

10

Power

Diesel

220HP

11

Oil pump

Model

Variable double-piston constant power

Pressure

31.5Mpa

Oil flow

125ml*2

Quantity

1set

Manufacture

12

Control system

PLC control

13

360 degree rotation grab

Large Amount Feeding Portable Automatic Scrap Car Baler Removable Style
