The hydraulic metal baler can compress scrap metal scraps, steel scraps, scrap steel, scrap iron, scrap copper, scrap aluminum, aluminum scraps, disassembly and assembly car shells, waste oil drums, etc. This series of machines is mainly suitable for recycling and processing industries and metal smelting industries.
Features of the baler
1. Hydraulic drive, compact design, great sealing;
2. Customized press box size and bale size;
3. Bale discharging ways include turn-out, side-push out and forward-out;
4. Designed with quick unit that can improve work efficiency substantially;
5. Famous motor, hydraulic system, oil cylinder, piston pump, electrical components;
6. Blades: our baler can compressing machinery scrap iron aluminum metal baler with the knife, it can cut the long size material when compressing, so it very goog for the long steel wire and big size material.
Technical Parameters
Model | Main Cyl.Force (ton) | Press Box Size | Bale Section | Bale Weight | Power |
Y81F-125 | 125 | 1200*700*600 | 300*300 | 50-70 | 15 |
Y81F-160 | 160 | 1600*1000*800 | 400*400 | 100-150 | 22 |
Y81F-200 | 200 | 1800*1400*800 | 260/300(octagon) | 50-100 | 37/44 |
Y81F-250 | 250 | 2000*1750*1000 | 500*500 | 250-450 | 60 |
Y81F-250 | 250 | 2500*2000*1200 | 500*500/600*600 | 300-500 | 60 |
Y81F-315 | 315 | 3000*2500*1200 | 600*600 | 400-700 | 90 |
Y81F-315 | 315 | 3500*3000*1300 | 600*600/700*700 | 600-1000 | 90 |
Y81F-315 | 315 | 4000*3000*1300 | 600*600/700*700 | 800-1200 | 90 |
Y81F-400 | 400 | 3500*3000*1300 | 600*600/700*700 | 800-1300 | 135 |
Y81K-400 | 400 | 4000*3000*1300 | 600*600/700*700 | 900-1300 | 135 |
Y81F-500 | 500 | 3500*3000*1300 | 600*600/700*700 | 900-1500 | 135 |
Y81K-500 | 500 | 3500/4000*3000*1300 | 600*600/700*700 | 900-1600 | 135 |
Y81K-630 | 630 | 3500/4000*3000*1400 | 600*600/700*700 | 1100-1700 | 165 |
Y81K-800 | 800 | 3500/4000*3000*1400 | 600*600/700*700 | 1200-1800 | 220 |
Y81F-1000 | 1000 | 3500/4000*3000*1500 | 600*600/700*700 | 1300-1900 | 275 |
Y81K-1500 | 1500 | 3500*3000*1500 | 700*700/800*800 | 1400-2100 | 330 |
Application
The baler Can Compressing Machinery Scrap Iron Aluminum Metal Baler is used to compress scrap metal(steel, copper, aluminum,stainless steel, etc)into metal block or metal bale. The purpose is to save the transportation cost or reduce the raw material loss when smelting.
Shipping
FAQ
Q1 : Can I add my logo on the machines?
A : Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q2 : How can i get the after-service?
A : We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems, we also send the spare parts, but you should pay.
Q3 : Do you have inspection procedures for machines?
A : 100% self-inspection before packing
Q4 : Can I have a visit to your factory before the order?
A : Sure, welcome to visit our factory.
Here is our factory address:No.29, Panlongshan Road, Jiangyin City, Jiangsu Province, China.
Q5 : Can we order one set machine?
A : Yes, you can.
