Portable Hydraulic Hose Crimper Manual Hose Crimper Automatic Pipe Crimper Hose Press
Portable Hydraulic Hose Crimper Manual Hose Crimper Automatic Pipe Crimper Hose Press
Portable Hydraulic Hose Crimper Manual Hose Crimper Automatic Pipe Crimper Hose Press
Portable Hydraulic Hose Crimper Manual Hose Crimper Automatic Pipe Crimper Hose Press
Specifications
Brand Name :
MENSION
Model Number :
MS-51L
Certification :
CE RoHS
Place of Origin :
CN
MOQ :
1 Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Sets Per Month
Delivery Time :
2 - 7 Working Days
Packaging Details :
One Plywood For One Set
Price :
Contact Us
Name :
Manual Hydraulic Hose Crimper High Precision
Crimping Range :
14-87mm
Hose Size :
1/4-2inch
Die Sets :
10
Max. Opening :
30mm
Crimping Force :
500T
System Pressure :
31.5Mpa
Power :
3KW
Size :
800*640*1300mm
Weight :
320Kg
Description

HIGH PRECISION PORTABLE MANUAL HYDRAULIC HOSE CRIMPER MS-51L

DESCRIPTION

MS-51L hose crimping machine is made with a human confort height, so the worker can operate the machine more easily. It has crimping dies range from 15mm to 63mm, suitable for high pressure hose with inner diameter from 6mm to 51mm one to four wire braided assembly producing.

MAIN ADVANTAGES

1) Double function foot pedal switch frees both the hands
2) 13 months warranty will be supplied based on the date of BL

3) Spare parts will be free if not human broken

TECHNICAL DATA

Model

MS-51L Manual Cable Crimping Machine

Crimping Range

14 - 87 (mm)

Crimping Force

500 (T)

Hose Size

1/4 - 2 (inch)

Max. Opening

30 (mm)

Die Sets

10

Die Set Type

51

System Pressure

31.5 (Mpa)

Accuracy

0.05 (mm)

Control

MS

Standard Voltage

220 (V) / 380 (V)

Motor Power

3 (KW)

Length

800 (mm)

Width

640 (mm)

Height

1300 (mm)

Weight

320 (KG)

Portable Hydraulic Hose Crimper Manual Hose Crimper Automatic Pipe Crimper Hose Press

NOTE

- Customized die sets are available;

- Special voltage 110V, 208V, 240V, 415V are availbale;

OPTIONAL

- Quick Change Tool

- UC control;

51 STANDARD DIE SETS

Die No.

Crimping Range

6*

6 - 8mm

8*

8 - 10mm

10*

10 - 12mm

12*

12 - 15mm

15

15 -1 9mm

19

19 - 23mm

23

23 - 26mm

26

26 - 31mm

31

31 - 36mm

36

36 - 41mm

41

41 - 47mm

47

47 - 55mm

55

55 - 63mm

63

63 - 69mm

69*

69 - 76mm

Portable Hydraulic Hose Crimper Manual Hose Crimper Automatic Pipe Crimper Hose Press
