Specifications
Brand Name :
FY
Model Number :
FY-P38
Certification :
CE
Place of Origin :
China,Shanghai
MOQ :
1 set
Price :
USD$ 1850/1800/1750/1700
Payment Terms :
L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability :
300 sets per month
Delivery Time :
2-7 working days
Packaging Details :
wooden box
Voltage :
220V/240V/380V/415V(Optional)
Gross Weight :
300kgs
Net Weight :
275kg
Power(w) :
3KW/4KW
Dimension(l*w*h) :
950*630*700 mm
Package Dimension :
1000*680*750 mm
Warranty :
1 Year
Condition :
New
After-sales service provided :
Video technical support,Online support
Crimping force :
300Ton
Product name :
CE approved 6-51mm high pressure hydraulic hose crimping machine
Crimping range :
6-38mm
Color :
Blue,blue or customize
Application :
Crimp Hose
Free dies :
8sets
System pressure :
26MPA/31.5MPA
Output Volume Of Pump :
2.5L/5L
HIGH LIGHT :
Advanced hydraulic pipe crimping machine, Dash control hydraulic pipe crimping machine, pipe crimping machine
Description

Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools

DESCRIPTION

P38 Stainless Steel Pipe Hose Crimping Machine

Introducing our Hose Crimping Machine P38, designed for high accuracy and efficiency in crimping stainless steel pipes and hoses. This Hose Crimping Machine P38 is designed for efficiency and precision, making it perfect for various applications.Hose Crimping Machine P38 Key features include:

  • High Precision Crimping: Ensures secure and reliable connections with exceptional accuracy, perfect for demanding applications.
  • Versatile Size Capability: Accommodates both 1.5 and 2-inch hoses, making it suitable for a wide range of projects.
  • Quick Change Mould Tools: Features a rapid mold change system, allowing for seamless transitions between different hose sizes.
  • Robust Rack Design: Built for stability and durability, ensuring consistent performance in various environments.

This crimping machine is ideal for professionals looking for reliability and precision in their hose assembly tasks. Enhance your operations with the P38 Braided Hose Crimper today!

THE MACHINE'S MAIN LEADING PLACES
1) Famous Brand valve system, high quality, long using time, low maintenance cost
2) Foot pedal frees the operator's hand for holding big size hydraulic hose
3) Advanced Dash control, multifunction for crimping work
4) Quick change for die sets enable die sets change all at one time

crimping range 6-38mm(1/4''-1.5''inner diameter of hose)
Rated pressure 26Mpa/31.5Mpa(Optional)
The largest crimping pressure 300T
Rular precision 0.01mm
Output volume of pump 2.5L/5L(Optional)
Net weight 275kg
Work efficiency 200pcs/h
size 950*630*700 mm
dies 8 sets
Item No.of dies length 60mm(15,19,23,26);Length 70mm(31,36,41);Length 80mm(47,55,60)

Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools

Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools

Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools

crimping range 6-38mm(1/4''-1.5''inner diameter of hose)
Rated pressure 26Mpa/31.5Mpa(Optional)
The largest crimping pressure 300T
Rular precision 0.01mm
Output volume of pump 2.5L/5L(Optional)
Net weight 275kg
Work efficiency 200pcs/h
size 950*630*700 mm
dies 8 sets
Item No.of dies length 60mm(15,19,23,26);Length 70mm(31,36,41);Length 80mm(47,55,60)




Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools

TECHNICAL DATA

Model FY-P38 Hose Crimping Machine
Crimping Range 6-38(mm)
Crimping Force 300(T)
Hose Size 1/4-1.5(inch)
Max. Opening 20±mm
Die Sets 8

Maximum Open Diameter

 104MM
System Pressure 26(Mpa)/31.5(Mpa)
Accuracy 0.01(mm)

Work Efficiency

 200 pcs/h
Standard Voltage

220v/240v/380v/415v(optional)
Motor Power 3(KW)/4(KW)
Length 950(mm)
Width 630(mm)
Height 700(mm)
Weight 275(KG)

NOTE

- for non standard die sets;

- Customized die sets are available;

- Special voltage 220V, 240V, 380V,415V are availbale;

► ADVANCED PLC SYSTEM
Multifucntional control panel with different operation mode

Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools

► DIE SETS
8 die sets hardness 59-63HRC, with quick change tool, productivity improve much.

Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools

► FAMOUS BRAND MOTOR
World famous motor with high stability

Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools

► ONE PIECE FORGED OIL CYLINDER
Forged cylinder has higher anti wear ability compared with traditional technology

Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools

► APPLICATIONS
FY-P38 is a high configured hose crimper, it has the ability of crimping high pressure stainless steel braided hydraulic oil hose, industrial fexible pipes, air or water hose, cable and wires, steel and iron tubes, brake lines in automotive system, air suspension or springs.

Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools

Stainless Steel Pipe Hose Crimping Machine P38 Braided Hose Crimper High Accuracy 1.5 And 2 Inch With Rack And Fast Change Mould Tools
