Specifications
Brand Name :
FY
Model Number :
FY-51BY
Certification :
CE
Place of Origin :
Shanghai,China
MOQ :
1 set
Price :
USD$1600/1500/1400/1300
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
300 sets per month
Delivery Time :
2-5 working days
Packaging Details :
wooden box
Weight :
310KG
Condition :
New
Dimension(l*w*h) :
860*640*1300MM
Warranty :
1 Year
After-sales service provided :
Video technical support,Online support
Voltage :
220v/240v/380v/415v(optional)
Power(w) :
3KW
Crimping force :
600T
Color :
blue or customize
Crimping range :
6-51mm
Product name :
hydraulic hose crimping machine,ce CE approved 6-51mm high pressure hydraulic hose crimping machine
Application :
Crimp Hose,rubber hose crimping
Free dies :
10sets
Rated pressure :
31.5MPA
Keywords :
hydraulic hose crimping machine, Vertical Rubber Hose Crimping Machine, 2 Inch Rubber Hose Crimping Machine,
Description

Easy to Operate 6-51MM hydraulic hose crimping machine for sale

THE DESCRIPTION OF APPLIANCE

Prevent dirt and other impurities from entering the hydraulic oil tank. If the pressure oil tank of the crimping machine enters the tiny impurity particles, they will scratch the plunger pump, jam the valve, block the oil port, and cause the crimping machine to malfunction.FY-51BY is a the third generation among the domestic types. It provide 600T crimping force, can be worked automatically or manually depends on different need. Foot pedal can make the hand free during crimping.

MAIN ADVANTAGES

1. Forged crimping clylinder, high hardness;

2. Multifunctional operate panel, easy to change between automatic and manual;

3. Pressure Gauge, system shown clearly during crimping;

4. Foot pedal as standard to make hands free;

5. Working light to make crimping work more clear.

6. Side die set install design, more covenient.

crimping range/skiving range
6-51mm(1/4''-2''inner diameter of hose)
quantity of dies
10 sets
item diesNo. of
length 60mm(15,19,23,26)
Length 70mm(31,36,41)
Length 80mm(47,55,60)
accuracy
0.01mm
output volume of pump
2.5L/5L/10L(Optional)
system pressure
26Mpa/31.5Mpa(Optional)
motor power
3kw/4kw 1,2,3 phase (Optional)
voltage
220V/380V/415V(Customizable) 50/60Hz
crimping force
500T
work efficiency
200pcs/h
maximum open diameter
114mm
the max open tolerance
±30mm
package dimension
900*680*1450mm
machine dimension
860*640*1300mm
Net weight
310kg
Gross weight
320kg

TECHNICAL DATA

Model FY-51BY Hose Crimping Machine
Crimping Range 6-51(mm)
Crimping Force 600(T)
Hose Size 1/4-2(inch)
Max. Opening 30mm
Die Sets 10

Work efficiency

 200PCS/H
System Pressure 31.5(Mpa)
Accuracy 0.01(mm)

Maximum Open Diameter

 114MM
Standard Voltage 220v/240v/380v/415v(optional)
Motor Power 3(KW)
Length 860(mm)
Width 640(mm)
Height 1300(mm)
Weight 310(KG)

500t Rubber Hose Crimping Machine 6-51mm Ferrule Hose Crimper Easy To Operate For Sale

500t Rubber Hose Crimping Machine 6-51mm Ferrule Hose Crimper Easy To Operate For Sale

NOTE

- For non standard die sets;

- Customized die sets are available;

- Special voltage 220v/240v/380v/415v(optional) are availbale;

OPTIONAL

- Quick Change Tool

- UC control

► MULTI FUNCTIONAL OPERATE PANEL

Human design, two operate mode, free change

500t Rubber Hose Crimping Machine 6-51mm Ferrule Hose Crimper Easy To Operate For Sale

► DIE SETS

6mm to 51mm die sets for hose from 1/4'' to 2'', die sets with high hardness, long service time

500t Rubber Hose Crimping Machine 6-51mm Ferrule Hose Crimper Easy To Operate For Sale

► FOOT PEDAL

Free hands for big hose, more convenient; Double usage, both closing and opening function

500t Rubber Hose Crimping Machine 6-51mm Ferrule Hose Crimper Easy To Operate For Sale

► OEM SERVICE

For different color, structure or die sets.

500t Rubber Hose Crimping Machine 6-51mm Ferrule Hose Crimper Easy To Operate For Sale

► WIDE APPLICATION

FY51BY is a 2 Inch hose crimping machine, which is capable of crimping hydrualic hose from 1/4'' to 2'', it can be used for quick jointing of material, like high pressure rubber oil hose, low pressure water or air pipes, cables, wires or ropes.

500t Rubber Hose Crimping Machine 6-51mm Ferrule Hose Crimper Easy To Operate For Sale

500t Rubber Hose Crimping Machine 6-51mm Ferrule Hose Crimper Easy To Operate For Sale

500t Rubber Hose Crimping Machine 6-51mm Ferrule Hose Crimper Easy To Operate For Sale

500t Rubber Hose Crimping Machine 6-51mm Ferrule Hose Crimper Easy To Operate For Sale
