Specifications
Brand Name :
DY-MED
Model Number :
DY115
Certification :
ISO13485&CE
Place of Origin :
China
MOQ :
1pcs
Price :
$200-$600/pcs
Payment Terms :
T/T, Western Union
Supply Ability :
2000 Piece/Pieces per Month
Delivery Time :
3-7working days
Product Name :
Syringe Pump
Display :
3.5 inch color LCD screen
OEM :
Available
Occlusion Level :
IP4
Working Mode :
6
Warranty :
2years
Description

Features:

Ø 3.5 inch LCD screen, multiple languages customization

Ø Wide range of flow rate:0.01-2000ml/h

Ø Comprehensive audible and visual alarm function, adjustable volume, visible from 360°

Ø Automatic recognition of syringe specifications(5ml,10ml,20ml,30ml,50/60ml)

Ø Change flow rate without stopping the current task

Ø Drug library mode, customized

Model No. Parameters DY115
Syringe Size 5,10,20,30,50/60ml
Drug Library Yes
Infusion Modes Flow Rate,Rate-Time,Rate-Volume,Time-Volume,
Body Weight,Drug Library
Drug Name Display Default 12 drugs, can be updated & added to 2000
Safety Double CPU to make sure higher standard infusion
Accuracy ±2%
Time Preset 0~99h and 59min
Volume Range 0.01~9999.99ml
Flow Rate Step by Increments at 0.01 ml/h
Flow Rate Range 5ml Syringe 0.01ml/h-150ml/h
10ml Syringe 0.01ml/h-400ml/h
20ml Syringe 0.01ml/h-600ml/h
30ml Syringe 0.01ml/h-900ml/h
50/60ml Syringe 0.01ml/h-1800ml/h
Purge/Bolus Rate/Top Flow Rate 5ml Syringe 150ml/h
10ml Syringe 400ml/h
20ml Syringe 600ml/h
30ml Syringe 900ml/h
50/60ml Syringe 1800ml/h
50/60ml Syringe 1200ml/h
Audible & Visible Alarms Syringe Dislocation,Occlusion,Near End,Pause Overtime,Low Battery,Battery Exausted,VTBI Completion,Syringe Empty,Motor Malfunction,Incorrect Syringe Specification,Circuit Malfunction,Internal Communication Malfunction,Master CPU Malfunction,Monitoring CPU Malfunction
KVO Rate≥10ml/h:KVO=3ml/h Rate＜10ml/h:KVO=1ml/h
Occlusion Pressure High: 106.7KPa±26.7 KPa
Middle: 66.7KPa±13.3 KPa
Low: 40.7KPa±13.3 KPa
Pause Overtime Alarm 1min50s—2min
Power & Battery 20VA, AC:100V-240V 50HZ/60HZ, DC:11.1V,Lithium battery support from 7 to10 hours
Classification Class II,type CF,IPX4
Dimension & Weight 140mm(width)×260mm(length)×110mm(height) ; 2.5Kg
Optional Function Event Log with at least 2000 history records,DC
