Batch Type Stationary Asphalt Mixing Plant Asphalt Processing Plant
Batch Type Stationary Asphalt Mixing Plant Asphalt Processing Plant
Batch Type Stationary Asphalt Mixing Plant Asphalt Processing Plant
Batch Type Stationary Asphalt Mixing Plant Asphalt Processing Plant
Batch Type Stationary Asphalt Mixing Plant Asphalt Processing Plant
Batch Type Stationary Asphalt Mixing Plant Asphalt Processing Plant
Specifications
Brand Name :
ZOOMLINE
Model Number :
ZAP-S40-400
Certification :
CE, ISO, EAC, EMC
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10 sets per month
Delivery Time :
about 30-40 days
Packaging Details :
40HQ container
Product name :
Hot Road Construction Plant
Capacity :
40-320t/h
Type :
Stationary, Batch mixing
Power(kw) :
According to the capacity
Color :
Client's Customized
Warranty :
15 Months
Description

Batch Type Stationary Asphalt Mixing Plant Asphalt Processing Plant

Product Description

ZAP-S series Stationary Batch Asphalt Mixing Plant are available from 40TPH to 320TPH, and is most popular for its high output and high performance.

Main advantages:

• Cost effective solutions for your project

• Multi-fuel burner for choose

• Environmental protection, energy saving, safe and easy to operate

• Low maintenance operation & Low energy consumption & Low emission

• Optional environmental design - sheeting and clad to customers requirements

• Rational layout, simple foundation, easy to be installed and maintenance

Drying System

- Optimizing the blade geometry of the dryer makes the drying and heating process extremely efficient, reduces energy consumption, and increases the heating efficiency by 30% compared with the conventional design; due to the high heating efficiency, the surface temperature of the drum is relatively low, so the cooling period after operation is greatly shortened.

- Completely insulated and composite aggregate drying drum. The support roller is driven by the friction of the motor and the gear unit.

- Adopting the famous brand Honeywell temperature intelligent control system.

Combustion system

- Using Italian brand high combustion efficiency burners to ensure low exhaust emissions (such as carbon dioxide, low NO1 & NO2, sulfur dioxide).

- Diesel, heavy oil, natural gas, coal or multi-fuel burners.

- Using international standard parts, the maintenance cost is low.

Technical parameters of 40-320tph Stationary Asphalt Mixing Plant

Items ZAP-S40 ZAP-S60 ZAP-S80 ZAP-S100 ZAP-S120 ZAP-S160 ZAP-S200 ZAP-S240 ZAP-S320
Plant Capacity 40t/h 60t/h 80t/h 100t/h 120t/h 160t/h 200t/h 240t/h 320t/h
Drying System
Drying drum size(mm)

1200

x5200

1200

x5500

1500

x6600

1500

x6600

1800

x8000

1900

x9000

2200

x9000

2600

x9500

2800

x10200
Drying capacity 40-60t/h 60-70t/h 80-100t/h 100-120t/h 120-140t/h 160-180t/h 200-220t/h 240-260t/h 320-360t/h
Burner (oil) kg/h 70-300 100-400 60-600 100-1000 100-1000 140-1400 180-1800 180-1800 250-2500
Fuel consumption (oil) 6.5-7kg/t 6.5-7kg/t 6.5-7kg/t 6.5-7kg/t 6.5-7kg/t 6.5-7kg/t 6.5-7kg/t 6.5-7kg/t 6.5-7kg/t

Batch Type Stationary Asphalt Mixing Plant Asphalt Processing Plant
